SYS86350V4GA
(v1.x) Industrial Computer Board
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYS86350V4GA and is the answer not in the manual?

Questions and answers

Related Manuals for Grantech SYS86350V4GA

Summary of Contents for Grantech SYS86350V4GA

  • Page 1 SYS86350V4GA (v1.x) Industrial Computer Board...

  • Page 2: Table Of Contents

    Preface CONTENTS Copyright Notice .................... ii Trademarks ....................ii Revision History .................... ii Technical Support ..................ii Safety Instructions ..................iii Chemical Substances Information ............... iv Battery Information ..................iv CE Conformity ....................v FCC-A Radio Frequency Interference Statement ......... v WEEE Statement ..................
  • Page 3 Appendix WDT & GPIO ..............A-1 WDT Sample Code ................... A-2 GPIO Sample Code .................. A-3...

  • Page 4: Overview

    Overview Thank you for choosing the SYS86350V4GA, an excellent industrial computer board. Based on the innovative Intel H81/ Q87 chipset for optimal system ® effciency, the 86350 accommodates the Intel Haswell processor ® and supports up to 2 DDR3/DDR3L 1333/1600 MHz SO-DIMM slots to provide the maximum of 16 GB memory capacity.

  • Page 5: Mainboard Specifications

    Overview Mainboard Specifications Processor ■ 4th generation Intel Core i3/ i5/ i7, Pentium, Celeron processor (LGA1150) Chipset ■ SKU1, SKU2: Intel H81 ■ SKU3: Intel Q87 Memory ■ 2 x DDR3/DDR3L 1333/1600 MHz SO-DIMM slots ■ Up to 16 GB ■...

  • Page 6: Form Factor

    Onboard Headers/ Connectors/ Jumpers ■ SKU1 ■ SKU2, SKU3 - 1 x 4-pin power connector - 1 x 4-pin power connector - 1 x 24-pin power connector - 1 x 24-pin power connector - 1 x system fan connector - 1 x system fan connector - 1 x CPU fan connector - 1 x CPU fan connector - 2 x SATA 6Gb/s ports...

  • Page 7: Mainboard Layout

    Overview Mainboard Layout SYS86350V4GA SKU1 COM Port Jumper Clear CMOS System Fan COM Port COM Port Connector Jumper Jumper Connector Back Panel Power COM Port Connector Jumper Header COM Port Connector COM Port Front Panel Jumper Header AT/ATX Jumper CPU Fan...
  • Page 8 SYS86350VGGA-10C SKU2, SKU3 COM Port Jumper Clear CMOS System Fan COM Port Jumper COM Port Connector Jumper Connector COM Port Back Panel Power Header Connector Jumper COM Port Connector COM Port Front Panel Jumper Header AT/ATX Jumper CPU Fan Connector Connector Power GPIO...

  • Page 9: Hardware Setup

    Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the com- ponents and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work prop- erly.
  • Page 10 Hardware Setup Components Reference Guide CPU (Central Processing Unit) ............2-3 Memory ....................2-6 Power Supply ..................2-8 System Power Connector: JPWR1 ............2-8 CPU Power Connector: JPWR2 ..............2-8 Rear Panel I/O ...................2-9 Connector ..................2-11 Fan Power Connector: CPUFAN1, SYSFAN1 ......... 2-11 GPIO Connector: JGPIO1 ................2-12 Serial ATA Connector: SATA1, SATA2 ............2-12 Audio Amplifier Connector: JSPK1 ............2-13 Front Audio Connector: JAUD1 ..............2-13...

  • Page 11: Cpu (Central Processing Unit)

    CPU (Central Processing Unit) When installing the CPU, make sure that you install the cooler to prevent over- heating. If you do not have the CPU cooler, consult your dealer before turning on the computer. Important Overheating Overheating will seriously damage the CPU and system. Always make sure the cooling fan can work properly to protect the CPU from overheating.

  • Page 12: Cpu Installation

    Hardware Setup CPU Installation When you are installing the CPU, make sure the CPU has a cooler attached on the top to prevent overheating. Meanwhile, do not forget to apply some thermal paste on CPU before installing the heat sink/cooler fan for better heat disper- sion.
  • Page 13 5. Secure the load lever with the hook 6. Make sure the four hooks are in proper under the retention tab. position before you install the cooler. Align the holes on the motherboard with the cooler. Push down the cooler until its four clips get wedged into the holes of the motherboard.

  • Page 14: Memory

    Hardware Setup Memory Dual-Channel Mode In Dual-Channel mode, make sure that you install memory modules of the same type and density in different channel DIMM slots. Recommended Memory Population Number of DIMMs installed DIMM1 (ch A) DIMM2 (ch B) Important •...

  • Page 15: Installing Memory Modules

    Installing Memory Modules 1. Unlock the DIMM slot by flip- ping open its side clips. 2. Vertically insert the DIMM into the DIMM slot. The DIMM has an off-center notch at the bottom that will only allow it to fit one way into the DIMM slot. Push the DIMM deeply into the DIMM slot.

  • Page 16: Power Supply

    Hardware Setup Power Supply System Power Connector: JPWR1 This connector allows you to connect a power supply. To connect to the power supply, make sure the plug of the power supply is inserted in the proper orienta- tion and the pins are aligned. Then push down the power supply firmly into the connector.

  • Page 17: Rear Panel I/O

    Rear Panel I/O SKU1 Mouse/ Keyboard Combo RJ45 GbE RJ45 GbE Port VGA Port LAN Port LAN Port DVI-D Port USB 2.0 VGA Port USB 2.0 USB 3.0 RJ45 GbE HDMI Port Port Port Port LAN Port SKU2, SKU3 Mouse/ Keyboard Combo RJ45 GbE...

  • Page 18: Hdmi Port

    Hardware Setup RJ45 GbE LAN Port The standard RJ45 LAN jack is provided for connection to the Local Area Network (LAN). You can connect a network cable to it. LED Status Description No link Active Yellow Linked Active LED Speed Blinking Data activity 10 Mbps connection...

  • Page 19: Connector

    Connector Fan Power Connector: CPUFAN1, SYSFAN1 The fan power connectors support system cooling fan with +12V. When con- necting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND.

  • Page 20: Gpio Connector: Jgpio1

    Hardware Setup GPIO Connector: JGPIO1 This connector is provided for the General-Purpose Input/Output (GPIO) periph- eral module. Serial ATA Connector: SATA1, SATA2 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. Important Please do not fold the SATA cable into a 90-degree angle.

  • Page 21: Audio Amplifier Connector: Jspk1

    Audio Amplifier Connector: JSPK1 The connector is used to connect audio amplifiers to enhance audio performance. Front Audio Connector: JAUD1 This connector allows you to connect the front panel audio and is compliant with Intel Front Panel I/O Connectivity Design Guide. Front Panel Header: JFP1 This front panel connector is provided for electrical connection to the front panel switches &...

  • Page 22: Rs-232/422/485 Serial Port Connector: Jcom1, Jcom2

    Hardware Setup RS-232/422/485 Serial Port Connector: JCOM1, JCOM2 This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. You can attach a serial device to it through an optional serial port bracket. RS-232 SIGNAL DESCRIPTION NDCD Data Carrier Detect NSIN Signal In...

  • Page 23: Rs-232 Serial Port Header: Jcom3, Jcom4

    RS-232 Serial Port Header: JCOM3, JCOM4 (JCOM4 for SKU2, SKU3 only) This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. You can attach serial devices to it through the optional serial port bracket. JCOM3 JCOM4 2-15...

  • Page 24: Usb 2.0 Connector: Jusb1

    Hardware Setup USB 2.0 Connector: JUSB1 This connector, compliant with Intel I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cam- eras, MP3 players, printers, modems and the like. Important Note that the pins of VCC and GND must be connected correctly to avoid pos- sible damage.

  • Page 25: Jumper

    Jumper Important Avoid adjusting jumpers when the system is on; it will damage the motherboard. Clear CMOS Jumper: JCMOS1 There is a CMOS RAM onboard that has a power supply from an external battery to keep the data of system configuration. With the CMOS RAM, the system can automatically boot OS every time it is turned on.

  • Page 26: Serial Port Power Jumper: Jcomp1, Jcomp2, Jcomp3, Jcomp4

    Hardware Setup Serial Port Power Jumper: JCOMP1, JCOMP2, JCOMP3, JCOMP4 (JCOMP4 for SKU2, SKU3 only) These jumpers specify the operation voltage of the onboard serial ports. +12V +12V Non-Volatile Memory Jumper: JNVM1, JNVM2, JNVM3, JNVM4 (JNVM3, JNVM4 for SKU1 only) This jumper is used to enable/disable the BIOS flash.
  • Page 27 HIDAC Utility This section introduces the GT HIDAC utility for overall system monitor and control. 2-4-1...
  • Page 28 Activating the Utility Select [GT HIDAC Utility] on Desktop to activate the utility. This GT HIDAC Utility provides information on: ■ GPIO (DIO) ■ Watchdog Timer ■ System Information ■ Hardware Monitor ■ Alarm Settings for Hardware Monitor ■ Alarm Logs for Hardware Monitor GPIO (DIO) Features: ■...

  • Page 29: System Info

    Watchdog Features: ■ Initial Timer configurable through WDT Settings ■ WDT Tools available for automatically activating Watchdog Timer at system boot and automatically resetting timer after a preset time interval ■ Real-time display of Watchdog Timer status System Info. Features: ■...
  • Page 30 HW Monitor Features: ■ Real-time display of Hardware Monitor status including CPU/system temperatures, fan speeds and voltages Alarm Settings Features: ■ Custom settings of a tolerance range for the alarm triggers ■ Automatic alarm logs of monitored hardware items when the alarm trigger thresholds are exceeded...
  • Page 31 Alarm Logs Features: ■ Real-time display of Hardware Monitor alarm logs ■ Alarm logs filterable by button (Information, Warning or Error) ■ Alarm logs clearable through Clear Logs...
  • Page 32 Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output). 2-A-1...
  • Page 33 WDT & GPIO WDT Sample Code SIO_INDEX_Port equ 04Eh SIO_DATA_Port equ 04Fh SIO_UnLock_Value equ 087h SIO_Lock_Value equ 0AAh WatchDog_LDN equ 007h WDT_UNIT equ 60h ;60h=second, 68h=minute, 40h=Disabled Watchdog timer WDT_Timer equ 30 ;ex. 30 seconds Sample code: ;Enable config mode dx, SIO_INDEX_Port al, SIO_UnLock_Value dx, al...

  • Page 34: Gpio Sample Code

    GPIO Sample Code  GPI 0 ~ GPI 3 GPI 0 GPI 1 GPI 2 GPI 3 IO Address 1C3Ah 1C0Eh 1C38h 1C38h SIO GPIO Register Sample code  GPO 0 ~ GPO 3 GPO 0 GPO 1 GPO 2 GPO 3 IO Address 1C0Ch...
