Attenuation
scale
Numerical
indication
Graphical
indication
Measurement
bandwidth
Audible
indicator
Accuracy
Terrestrial
bands
Satellite band
Out of range
indication
RF MEASUREMENTS
Terrestrial bands
Analogue
channels
Digital
channels
Satellite band
Analogue
channels
Digital
channels
SPECTRUM ANALYSER MODE
Measurement range
Satellite band
Terrestrial
bands
Measurement bandwidth
Terrestrial
Satellite
Span
Terrestrial
Satellite
Markers
Reference
level
August 2012
Auto-range.
Absolute value according to selected units.
Analogue bar on screen.
100 kHz.
Pitch sound. A tone with pitch proportional to signal strength.
±1,5 dB (25-120 dBµV, 45-1000 MHz) (22 °C ± 5 °C).
±1,5 dB (35-100 dBµV, 950-2050 MHz) (22 °C ± 5 °C).
<, >.
Level, Video-Audio ratio, Carrier-Noise ratio.
Channel power, Carrier-Noise ratio.
Level and Carrier-Noise ratio.
Channel power and Carrier-Noise ratio.
10 dBµV to 130 dBµV (3.16 µV to 3.16 V).
10 dBµV to 130 dBµV (3.16 µV to 3.16 V).
100 kHz.
100 kHz.
Full span (full band) - 500 - 200 - 100 - 50 - 20 - 10 MHz
selectable.
Full span (full band) - 500 - 200 - 100 - 50 - 20 - 10 MHz
selectable.
1 with frequency and level indication.
65 dBµV to 135 dBµV, adjustable in steps of 5 dB.
7-57
