ClearSpan
House-Attached Carport
Photo may show a different but similar model.
™
STK#
DIMENSIONS
105589
11' W x 11'4" H x 12' L
105590
11' W x 11'4" H x 16' L
105591
11' W x 11'4" H x 20' L
105592
11' W x 11'4" H x 24' L
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ClearSpan 105589
Summary of Contents for ClearSpan 105589
- Page 1 ClearSpan ™ House-Attached Carport Photo may show a different but similar model. STK# DIMENSIONS 105589 11' W x 11'4" H x 12' L 105590 11' W x 11'4" H x 16' L ©2007 ClearSpan™ All Rights Reserved. Reproduction is prohibited 105591 11' W x 11'4"...
-
Page 2: Safety Precautions
• Identify whether underground cables and pipes are present before preparing the site or anchoring the Thank you for purchasing this ClearSpan™ shelter. When structure. properly assembled and maintained, this product will provide years of reliable service. These instructions include •... -
Page 3: Assembly Procedure
These words and phrases are common to most ClearSpan™ shelters and identify the different parts of the • Tek Screw: A self-tapping fastener used to secure pipe shelter. -
Page 4: Required Tools
NOTE: At this time, you do not need to open the plastic bags containing the fasteners (if used). QUICK START GUIDE For a quick overview of this shelter and its components, consult the Quick Start Guide at the back of these instructions. Visit www.ClearSpan.com for additional products and customer assistance. - Page 5 (Not all parts are shown.) FA4482B 100441 102921B Tek Screw Nut Setter Neo-bonded Galvanized Washer QH1070 104625 105088 105087 Pipe Strap 2-Way Pipe Fitting Connection Plate 1-Way Connector Visit www.ClearSpan.com for additional products and customer assistance.
- Page 6 1. Locate the required parts for each assembly procedure. 2. Assemble base rails and rafters. 3. Assemble frame. 4. Attach struts to frame. 5. Install hat channel and roof panels. Connection Plate Strut Visit www.ClearSpan.com for additional products and customer assistance.
- Page 7 (#104625) as shown. Secure each pipe using a Tek screw. #24CP23P1 #105561 Tek screws Tek screws Typical Main Rafter Assembly 2. Insert the swaged ends into the plain ends of the pipes to assemble the main rafter. #S20P066 Visit www.ClearSpan.com for additional products and customer assistance.
- Page 8 4. Install one Tek screw at each splice on each side of the rail to secure the two tubes. DO NOT install the Tek screws on the top or bottom surface of the base rail. Top of Base (3" wide) Tek screw Visit www.ClearSpan.com for additional products and customer assistance.
-
Page 9: Frame Assembly
NOTE: Rafter spacing is measured center-to-center. SITE COMMENT: For proper assembly of the frame, a 5. After the base rails are assembled, continue with the level site is required for the base rail. FRAME ASSEMBLY. Visit www.ClearSpan.com for additional products and customer assistance. - Page 10 ATTENTION: Fasteners to secure the frame to frame during assembly. the permanent structure are not included. Contact Customer Service or a reliable contractor for the proper fasteners based on the exterior material of the permanent structure. Visit www.ClearSpan.com for additional products and customer assistance.
- Page 11 1/2" through the pipe strap at that location. Do not allow the purlin pipe to extend beyond the edge of the rafter. 12. Secure the rafter to the 1-Way connector on the base rail. Visit www.ClearSpan.com for additional products and customer assistance.
- Page 12 17. After all rafters are secured to the bottom rail and to structure are properly installed and tight. the permanent structure, take the remaining purlin and 22. Continue by installing the diagonal struts. slide it into the lower pipe straps. Visit www.ClearSpan.com for additional products and customer assistance.
- Page 13 4. Repeat the steps to install the final 7' strut. 5. Continue by installing the hat channel and roof panels. 2. Secure the strut to the base of the interior rafter using a Tek screw. Tek screw Inside View Visit www.ClearSpan.com for additional products and customer assistance.
- Page 14 This procedure describes one way to attach the hat channel to the frame. Shelter #105589: 1 full section of hat channel per run. Shelter #105590: 1 and 1/2 sections per run. (Cut 3 1. Take one section of hat channel and align it at the top full pieces of hat channel in half to be used with the full of the frame as shown below.
- Page 15 NOTE: Use two Tek screws at each rafter to secure each run of hat channel. Visit www.ClearSpan.com for additional products and customer assistance.
- Page 16 NOTE: Use a chalk line to mark the location of the center of the hat channel (if desired). This helps to keep the screws aligned. Install all Tek screws and washers in the valleys of the panels. Visit www.ClearSpan.com for additional products and customer assistance.
- Page 17 NOTE: The Tek screw at the top of the panel and closest to the first panel will secure the two long panels and the two short wall profile sections to the upper hat channel run. Visit www.ClearSpan.com for additional products and customer assistance.
-
Page 18: Care And Maintenance
• For replacement or missing parts, call 1-800-245-9881 for assistance. NOTE: With the exception of Truss Arch buildings, ClearSpan™ shelters and greenhouses do not have any tested loading criteria. Visit www.ClearSpan.com for additional products and customer assistance. - Page 19 CLEARSPAN CARPORTS ™ QUICK START GUIDE 11' Wide House-Attached Carport Frame shown may differ in length from actual frame. Visit www.ClearSpan.com for additional products and customer assistance.
- Page 20 CLEARSPAN CARPORTS ™ Visit www.ClearSpan.com for additional products and customer assistance.
- Page 21 CLEARSPAN CARPORTS ™ Visit www.ClearSpan.com for additional products and customer assistance.
- Page 22 CLEARSPAN CARPORTS ™ Visit www.ClearSpan.com for additional products and customer assistance.
- Page 23 CLEARSPAN CARPORTS ™ Visit www.ClearSpan.com for additional products and customer assistance.
- Page 24 CLEARSPAN CARPORTS ™ Visit www.ClearSpan.com for additional products and customer assistance.
- Page 25 CLEARSPAN CARPORTS ™ Visit www.ClearSpan.com for additional products and customer assistance.
- Page 26 CLEARSPAN CARPORTS ™ Visit www.ClearSpan.com for additional products and customer assistance.
- Page 27 CLEARSPAN CARPORTS ™ Space below is reserved for customer notes. Visit www.ClearSpan.com for additional products and customer assistance.
