7. HEADPHONES OUT knob
This adjusts the output volume from the
8. (Headphones) jack
Connect stereo headphones here.
9. Category buttons
These buttons select the drum kit. Pressing a button within a category will select the next
drum kit within that category, in sequential order.
10. Power button
Turns the power on/off (→ p.12 "Turning the power on and off").
11. AMBIENCE fader
This adjusts the ambience effect (the presence of the sound) for the drum kit. This gives
the sound greater depth and adds reverberation.
Note:
The ambience effect cannot be used on some sounds.
Note:
The AMBIENCE fader may be set to not function on some preset drum kits (→
p.59 "Preset Drum Kit List").
To enable the AMBIENCE fader, set the "Inst Amb Max Level" in the CUSTOM
menu to a value greater than "Inst Amb Min Level." (→ p.21 "Inst Amb Max
Level")
Note:
When you have modified a drum kit or when you press the CUSTOM button to
enter user edit mode, the ambience level will be set to the ambience level saved in
the drum kit (→ p.21 "Kit Amb Level"). For this reason, the actual value may
differ from the value indicated by the AMBIENCE fader position.
12. EXIT button
Use this button to return to the previous page or to cancel setting the parameters.
13. BALANCE knob, SONG START/STOP button
This adjusts the volume balance sent to the headphones for each track using the song
function.
The music track volume will increase as you turn the knob to the left, and decrease as you
turn the knob to the right. Conversely, the click track volume will decrease as you turn the
knob to the left, and increase as you turn the knob to the right.
Also, push this knob (SONG START/STOP button) to start and stop the song.
The click track sound will not be routed to the MASTER OUT L/MONO, R jacks.
14. MASTER OUT knob
Adjusts the output volume from the MASTER OUT L/MONO, R jacks.
Note:
The sound output from the DIRECT OUT jacks cannot be adjusted.
(Headphones) jack.
