Appendix E: Remote Control Commands
Handoffs
E–52
When testing a dual mode mobile station, the tester can instruct the mobile
station to handoff the call from the digital mode to the analog mode or, in some
cases, vise versa. This simulates the handoff of a call from a CDMA or TDMA
(Option B84) base station to an analog base station or an analog base station to a
TDMA base station. Option B82 (Analog mode) must be installed to support any
handoff. Option B84 (TDMA mode) must be installed to support the TDMA
digital/analog handoffs.
You must first select which protocol you want to hand off to. You accomplish
this with the command CONFigure:HANDoff:COMBination <network>,
<system>, <standard> (query, CONFigure:HANDoff:COMBination?).
Table E–2 lists the supported handoff combinations of networks, systems, and
standards.
The command PROCedure:CTMStation:HANDoff performs the handoff.
Table E–2: Valid network handoffs
Network
US Cellular
Japanese Cellular
Chinese Cellular
US PCS
The following subsections describe setting up the base stations you intend to
make the handoff to.
CMD 80 Digital Radiocommunication Tester User Manual
Handoff from standard Valid handoff to standards
CDMA (IS–95) AMPS or NAMPS
AMPS NAMPS
NAMPS AMPS
AMPS TDMA (IS–136–A)
TDMA (IS–136–A) AMPS
TDMA (IS–136–A) US PCS TDMA (IS–136–A)
CDMA (IS–95) JTACS or NTACS
J–CDMA (T53) JTACS or NTACS
JTACS NTACS
NTACS JTACS
CDMA (IS–95) ETACS or TACS
CDMA (UB IS–95) AMPS or NAMPS
CDMA (J–STD–008) AMPS or NAMPS
TDMA (IS–136–A) AMPS
TDMA (IS–136–A) US Cellular TDMA (IS–136–A)
