Appendix F: Remote Control Command Tables
Table F–39: TDMA IS-136-A module test menu: adjacent channel power – configuration (cont.)
Command
CONFigure:DAMM[:TQUality]:LIMit:ACPower:PEAK:CH1Plus[:UPPer] <peak power limit
[DBC]>
Sets the Pass/Fail peak threshold of the frequency domain Adjacent Power measurement.
The keyword CH1Plus represents the channel that is one channel above the current channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:PEAK:CH1Plus[:UPPer]?
Returns the set Pass/Fail peak threshold of the frequency domain Adjacent Power
measurement of the channel that is one channel above the current channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:RMS:CH2Plus[:UPPer] <RMS power limit
[DBC]>
Sets the Pass/Fail RMS threshold of the frequency domain Adjacent Power measurement.
The keyword CH2Plus represents the channel that is two channels above the current
channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:RMS:CH2Plus[:UPPer]?
Returns the set Pass/Fail RMS threshold of the frequency domain Adjacent Power
measurement of the channel that is two channels above the current channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:PEAK:CH2Plus[:UPPer] <peak power limit
[DBC]>
Sets the Pass/Fail peak threshold of the frequency domain Adjacent Power measurement.
The keyword CH2Plus represents the channel that is two channels above the current
channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:PEAK:CH2Plus[:UPPer]?
Returns the set Pass/Fail peak threshold of the frequency domain Adjacent Power
measurement of the channel that is two channels above the current channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:RMS:CH3Plus[:UPPer] <RMS power limit
[DBC]>
Sets the Pass/Fail RMS threshold of the frequency domain Adjacent Power measurement.
The keyword CH3Plus represents the channel that is three channels above the current
channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:RMS:CH3Plus[:UPPer]?
Returns the set Pass/Fail RMS threshold of the frequency domain Adjacent Power
measurement of the channel that is three channels above the current channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:PEAK:CH3Plus[:UPPer] <peak power limit
[DBC]>
Sets the Pass/Fail peak threshold of the frequency domain Adjacent Power measurement.
The keyword CH3Plus represents the channel that is three channels above the current
channel.
CONFigure:DAMM[:TQUality]:LIMit:ACPower:PEAK:CH3Plus[:UPPer]?
Returns the set Pass/Fail peak threshold of the frequency domain Adjacent Power
measurement of the channel that is three channels above the current channel.
F–160
Values
–80.0
–26.0
0
–80.0
–45.0
0
–80.0
–45.0
0
–80.0
–45.0
0
–80.0
–45.0
0
CMD 80 Digital Radiocommunication Tester User Manual
State Notes
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
