Appendix F: Remote Control Command Tables
Table F–11: Analog manual test (signaling) commands (cont.)
Command
CONFigure:ARQuality:AFResponse:LIMit:LOWer:LEVel:LOWer
<lower level of lower limit [DB]>
Establishes the lower level of the lower limit line for the audio frequency response measure-
ment.
CONFigure:ARQuality:AFResponse:LIMit:LOWer:LEVel:LOWer?
CONFigure:ARQuality:AFResponse:LIMit:LOWer:LEVel:UPPer
<upper level of lower limit [DB]>
Establishes the upper level of the lower limit line for the audio frequency response
measurement.
CONFigure:ARQuality:AFResponse:LIMit:LOWer:LEVel:UPPer?
CONFigure:ARQuality:AFResponse:LIMit:UPPer:COUNt?
Query only. Returns the number (count) of points which designate the upper limit line for the
audio frequency response measurement.
CONFigure:ARQuality:AFResponse:LIMit:UPPer:GRAPh:X?
Query only. Returns the horizontal (X–axis) graph positions for each of the points which
designate the upper limit line of the audio frequency response measurement.
CONFigure:ARQuality:AFResponse:LIMit:UPPer:GRAPh:Y?
Query only. Returns the vertical (Y–axis) graph positions for each of the points which
designate the upper limit line of the audio frequency response measurement.
CONFigure:ARQuality:AFResponse:LIMit:UPPer:LEVel <upper limit level [DB]>
Establishes the level of the upper limit line for the audio frequency response measurement.
CONFigure:ARQuality:AFResponse:LIMit:UPPer:LEVel?
CONFigure:ARQuality:AFResponse[:SETTings]:DEFault
Resets all receiver quality audio frequency response settings to the default values.
CONFigure:ARQuality:AFResponse:SOURce:FM:DEViation:MODulation <peak deviation
[HZ]>
Establishes the base station modulation peak deviation for the audio frequency response
measurement.
CONFigure:ARQuality:AFResponse:SOURce:FM:DEViation:MODulation?
18
Some Limit values are dynamic and depend on the settings for associated limits (limit settings on the same axis of the
graph).
F–76
Values
–150 dB to
–6.0 dB to
0.9 dB
–150.0 dB to
–3.0 dB to
0.9 dB
4
50 Hz to
4000 Hz
–2.9 dB to
1.0 dB to 4.0 dB
0 Hz to 2900 Hz
to 8800 Hz
CMD 80 Digital Radiocommunication Tester User Manual
State Notes
17
ALL
ALL
18
ALL
ALL
ALL
ALL
ALL
18
ALL
ALL
ALL
ALL
ALL
