Tektronix CMD 80 User Manual page 306

CMD 80 Digital Radiocommunication Tester User Manual
DEFAULTS. Press this softkey to set all the parameters to their preset
conditions. Typically, the default values are based on the TDMA IS-136
specifications.
TRANSMITTER QUALITY. Press this softkey (see Figure 3–182 on page 3–230) to
display the TDMA MANUAL TEST TX QUAL CNFG menu, which has
selections that you use to set parameters for the various transmitter quality tests.
See Figure 3–189.
Figure 3–189: TDMA manual test transmitter quality configuration menu
Each of the transmitter quality configuration menu choices is discussed in the
following text.
ADJACENT CHANNEL PWR. Press this softkey to display the ADJACENT
CHANNEL PWR configuration menu (see Figure 3–190). This is the
TDMA: Configuration
3–237
