- Page 1 650-6183-00 and 650-6184-00 RSA7100 and CTRL7100 Series Packaging Kit Instructions www.tek.com 071-3736-00...
- Page 2 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
- Page 3 Table of Contents Packaging kit parts lists .................... 650-6183-00 CTRL7100 packaging procedure ..............650-6184-00 RSA7100 packaging procedure ..............RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 4 Table of Contents RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 5 BOX, SHIPPING, RSC (for accessories) 004-6118-xx CUSHION MATERIAL; PACKAGING FOR RSA7100 CONTROLLER 006-8267-xx BAG - PLASTIC, 32 X 32 X .004 THK LDPE 071-3736-xx [This document.] CTRL7100 AND RSA7100 SERIES PACKAGING KIT INSTRUCTIONS RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 6 WARNING. Injury may occur when lifting heavy objects. The CTRL7100 is a heavy instrument. To avoid injury, ensure proper lifting technique using at least two people when performing the procedures in this document. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 7 650-6183-00 CTRL7100 packaging procedure 1. Using at least two people, slide 32" x 32" bag [006-8267-xx] around unit and taped closed. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 8 650-6183-00 CTRL7100 packaging procedure 2. Make box [004-5964-xx] and place 2 foam pieces [004-5965-xx] in as shown. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 9 650-6183-00 CTRL7100 packaging procedure 3. Install the following 3 foam pieces as shown: one 004-5966-xx, two 004-5967-xx. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 10 650-6183-00 CTRL7100 packaging procedure 4. Using at least two people, lift controller and place in box with blue pieces, as shown. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 11 650-6183-00 CTRL7100 packaging procedure 5. Insert foam pieces [004-5966-xx] and [004-5968-xx], as shown, with cutout aligning with tab on controller. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 12 650-6183-00 CTRL7100 packaging procedure 6. Place 2 foam pieces [004-5965-xx] as shown. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 13 650-6183-00 CTRL7100 packaging procedure 7. Close and tape box. Attach label 1 of 3 to this box, as shown. 8. Add "Band on Pallet" sheet on box as shown. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 14 A mechanical lift can also be used. 1. Install a cardboard protector to the rear of the instrument, as shown, to protect the connectors. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 15 2. Open the 32" x 32" bag [006-8267-xx] and place it on the floor. Place the unit on its side, with handle up, onto the bag. Lift unit up and pull the bag up and around unit. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 16 3. Form box [004-5969-xx]. Place part of foam packaging [044-6118-xx] into box bottom. Locate cutout for connectors (see outlined area in image). 4. Using two people or mechanical lift, lower unit into box, ensuring connectors line up with cutout. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 17 650-6184-00 RSA7100 packaging procedure 5. Tape bag closed as shown. 6. Place other foam piece [044-6118-xx] on top of unit and align cutout with connectors. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 18 650-6184-00 RSA7100 packaging procedure 7. Close and tape box. Attach label 2 of 3 to this box, as shown. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
- Page 19 (004-5973-xx) and fill all voids with bubble wrap or like material to secure items in place. 9. Close and tape the accessories box and attach the label to the box. RSA7100 and CTRL7100 Series Packaging Kit Instructions...
