- Page 1 ™ ExtremeCloud Appliance E2120 Installation Guide 9035638 Published August 2018...
-
Page 2: Legal Notice
Copyright © 2018 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made. -
Page 3: Table Of Contents
Table of Contents Chapter 1: Overview........................4 Package Contents.................................4 Hard Drive LED Indicator Patterns..........................4 Chapter 2: Hardware Installation..................... 5 Mounting the Appliance..............................5 Attaching the Front Bezel..............................5 Connecting to a Power Source............................6 Installing a Power Supply..............................8 Removing a Power Supply............................... 9 Replacing a Power Supply.............................. -
Page 4: Chapter 1: Overview
Overview Package Contents Hard Drive LED Indicator Patterns Package Contents An E2120 Appliance ships with the following: • E2120 Cloud Appliance • Two rack handles and appropriate screws • One AC power cord bracket and cable clamp kit • One rack mounting kit •... -
Page 5: Chapter 2: Hardware Installation
Hardware Installation Mounting the Appliance Attaching the Front Bezel Connecting to a Power Source Installing a Power Supply Removing a Power Supply Replacing a Power Supply To prepare for Hardware Installation of E2120: Match the model number on the purchase order with the model numbers in the packing list and on the E2120 appliance. -
Page 6: Connecting To A Power Source
Hardware Installation Lock the right end of the front bezel to the rack handle (see letter “A” in Figure). Figure 1: Attaching the Optional Front Bezel 2 Rotate the front bezel clockwise until the left end clicks into place (see letter “B” in Figure). 3 Lock the bezel if needed. - Page 7 Hardware Installation Item Description RMM4 NIC Port (not used, plugged) Data Port 1, 1GbE RJ45(Port1) Data Port 2, 1GbE RJ45(Port2) Data Port 3, 1/10GbE SFP+(Port3) Data Port 4, 1/10GbE SFP+(Port4) 2 Connect the two AC power cables to power supplies 1 and 2. These two power supplies combine to create an optional redundant power supply.
-
Page 8: Installing A Power Supply
Hardware Installation Figure 4: E2120 Front Control Panel Item Description System ID Button w/ Integrated LED NMI Button Mgmt Port Activity LED Not Used System Cold Reset Button Drive Activity LED System Status LED Power Button w/ Integrated LED Installing a Power Supply The system requires one power supply to opearte normally. -
Page 9: Removing A Power Supply
Hardware Installation Remove the insert from the chassis power supply bay. Figure 5: Power supply insert chassis 2 Insert the power supply module into the power supply bay. Figure 6: Installing a Power Supply 3 Push the power supply module into the bay until it locks into place. Removing a Power Supply If you are removing a power supply: Detach the power supply cord from the power supply that needs to be removed. -
Page 10: Replacing A Power Supply
Hardware Installation Replacing a Power Supply The appliance will support two power supplies, supplying hotpluggable power redundancy. The system distributes the power load across both power supplies to maximize efficiency. When a power supply is removed with the system powered on, the full power load is picked up by the remaining power supply. Note The system ships with just one power supply and you have the option to purchase the additional power supply (Ordering Part No. -
Page 11: Chapter 3: Initial Network Connection And Configuration
Initial Network Connection and Configuration Configuring the Management Interface via Console Port Configuring the Management Interface via Management Port Connecting the Data Ports Configuring the Management Interface via Console Port Note The E1120 must be upgraded to the latest ExtremeCloud Appliance firmware before installing the appliance on the network. -
Page 12: Configuring The Management Interface Via Management Port
5 Complete the installation to configure the E1120 for new deployments. 6 Disconnect your laptop from the appliance’s management port. 7 Connect the appliance’s management port to the enterprise Ethernet LAN. 8 Log on to Extreme Networks. Note The system is now visible to the enterprise network. Refer to the... - Page 13 3 Verify that the RJ45 connectors on the twisted pair segment have the proper pinouts and check the cable for continuity. 4 If a link is not established, contact Extreme Networks. Data ports 3 and 4 provide SFP+ ports that can support both 1 G and 10G pluggable transceivers. Refer to the datasheet at the following location for a list of pluggable transceivers supported for the E2120:www.extremenetworks.com/...
-
Page 14: Chapter 4: E2120 Specifications
E2120 Specifications Physical Specifications • Dimensions Height: 43.9mm (1.73") • Width: 750mm (29.5") • Depth: 438mm (17.25") Environmental Specifications Operating Temperature 5°C to 35°C (32°F to 95°F) Storage Temperature -40°C to 70°C (-40°F to 158°F) Operationg Relative Humidity 0% to 90% (non-condensing) ExtremeCloud™... -
Page 15: Chapter 5: Regulatory Information
Regulatory Information FCC Notice (Part 15 - Class A) Industry Canada Notice CE Notice Japan (VCCI) - Voluntary Control Council for Interference Class A ITE BSMI EMC Statement - Taiwan Supplement to Product Instructions Hazardous Substances European Waste Electrical and Electronic Equipment (WEEE) Notice FCC Notice (Part 15 - Class A) This device complies with Part 15 of the FCC rules. -
Page 16: Ce Notice
Regulatory Information Class A ITE Notice Warning This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Klasse A ITE Anmerkung Warning WARNHINWEIS: Dieses Produkt zählt zur Klasse A ( Industriebereich ). -
Page 17: Supplement To Product Instructions
Regulatory Information Supplement to Product Instructions ExtremeCloud™ Appliance E2120... -
Page 18: Hazardous Substances
Regulatory Information Hazardous Substances This product complies with the requirements of Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2012/19/EU of the European Parliament on waste electrical and electronic... -
Page 19: Index
Index attaching front bezel 5 cables, sfp+ ports 13 Configuration, Console Port 11 configuration, E1120 Initial Setup 11 Configuration, Management Port 12 data ports 12 E2120 Overview 4 E2120 Specifications 14 Hardware Installation 5 LEDs 4 package contents 4 power source, power 6 power supply, installation 8 rack installation, mounting 5 remove, power supply 9 replace, power supply 10 ExtremeCloud™...
