Related Manuals for Zip Aquapoint AP430S SmartEco
Summary of Contents for Zip Aquapoint AP430S SmartEco
-
Page 1: Model Number
Installation instructions & user manual Aquapoint Direct unvented water heaters. Model number: (AP430S - AP4100S) SmartEco Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 2: Table Of Contents
• Please leave these instructions with the end user after installation. Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 3: General Product Description
General product description • These instructions will guide you through the installation, maintenance and use of the Zip Aquapoint, however, if you require any further information please call Zip customer service on 0345 6 005 005. • The Zip Aquapoint is an unvented water heater designed for connection directly to incoming mains water supply and can serve one or more outlets using conventional taps. -
Page 4: Technical Data
2_37 3_16 [hr_min] Packaging dimensions 1070 1245 (1) EU Regulation 812/2013 ; EN 50440 (2) EN 50440 Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 5: Safety Information
Repairs must only be carried out by a competent person. • Do not reset the over temperature cut-out until the cause of its operation Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S... - Page 6 To ensure proper functioning of the safety valve, the user should perform regular inspection and maintenance to remove lime scale and make sure Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk...
-
Page 7: Cautions
The Aquapoint is intended for connection to mains supply only. In any other case please contact Zip on 0345 6 005 005 for advice. • Zip Water UK cannot be held liable for any damages caused by failure to observe these instructions. Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 8: Spare Parts
95077 Electronic module AQ0315 Insulating bush 95082 Sensor strip 95078 Cable for sensor P&T valve Fig. 1 Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 9: Components Supplied With The Unit For Site Fitting
To facilitate future service interventions, you are advised to install the heater in accordance with the installation measurements (see Fig. 3 and Fig. 7). Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S... -
Page 10: Dimensions
As the water cannot return to the water supply system, this Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 11: Pressure Relief Valve
When the heater is filled with water, the water starts to run through the outlet pipe of the mixing tap. Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S... -
Page 12: Schematic Diagrams
Expansion relief valve to drain via tundish Check valve Pressure reducing valve Isolating valve (not supplied) Drain valves (not supplied) Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 13: Connection To The Electricity Supply
Ensure that the cover panel is replaced correctly and the retaining screws fitted before re-connecting the electrical supply. Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S... -
Page 14: Electrical Wiring Diagram
Connection terminal Temperature sensor Live conductor Thermal cut-out Neutral conductor Electronic regulator Electrical heating element Earthing conductor Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 15: Discharge Pipe Arrangement
Note It is not acceptable to discharge straight into a soil pipe. For guidance See G3 3.60. Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S... -
Page 16: Operation
Freeze protection temperature 10°C. Water temperature 35°C. Water temperature 57°C. Note all temperature values Water temperature 75°C. are nominal. Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... - Page 17 It can be started by holding button • The recording period lasts 7 days. Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S...
-
Page 18: Service & Maintenance
For this purpose it is advisable to install a T- piece with an outlet valve between the inlet pipe and safety valve. Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk... -
Page 19: Troubleshooting
3 seconds. Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S... -
Page 20: End Of Life Disposal
In order to preserve our environment we ask that you dispose of this product cor- rectly. Please contact Zip Customer Service for advice on 0345 6 005 005. Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S... -
Page 21: Warranty
Furthermore, this warranty does not displace any statutory warranty, but, to the extent to which Zip is entitled to do so, the liability of Zip under any statutory warranty will be limited at Zip’s option to the replacement of the Aquapoint or supply of equivalent Aquapoint, the payment of the cost of replacing the Aquapoint or acquiring an equivalent Aquapoint, or the payment of the cost of having the Aquapoint repaired or the repair of the Aquapoint. - Page 22 Notes Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk...
- Page 23 Notes Installation instructions & user manual Technical support Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S...
-
Page 24: Contact Details
Zip Water UK 14 Bertie Ward Way, Dereham, Norfolk NR19 1TE 0345 6 005 005 sales@zipindustries.co.uk www.zipwater.co.uk Installation instructions & user manual Technical support T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk...
