Zip Hydroboil Plus
Instant boiling water
203562 Zip Hydroboil Plus 3 Litre White
203561 Zip Hydroboil Plus 3 Litre Stainless Steel
205562 Zip Hydroboil Plus 5 Litre White
205561 Zip Hydroboil Plus 5 Litre Stainless Steel
207562 Zip Hydroboil Plus 7.5 Litre White
207561 Zip Hydroboil Plus 7.5 Litre Stainless Steel
Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00
Installation and Operating Instructions
®
HP003
HP103
HP005
HP105
HP007
HP107
Page 1 of 16
Advertisement
Table of Contents
Related Manuals for Zip Hydroboil Plus 3 Litre White HP003
Summary of Contents for Zip Hydroboil Plus 3 Litre White HP003
- Page 1 205561 Zip Hydroboil Plus 5 Litre Stainless Steel HP105 207562 Zip Hydroboil Plus 7.5 Litre White HP007 207561 Zip Hydroboil Plus 7.5 Litre Stainless Steel HP107 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00 Page 1 of 16...
- Page 2 This page intentionally left blank Page 2 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00...
-
Page 3: Table Of Contents
All plumbing and electrical installations must comply with local authority requirements. Page 3 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 4: Read These Warnings First
A suitable form of water treatment may be necessary. All plumbing connections must be made in accordance with local regulations. The Zip Hydroboil Plus instant boiling water heater is not intended for use by young children or infirm people without supervision. -
Page 5: Step 1 - Positioning
Install plumbing and wiring and prepare pipe ends and wiring ends as shown. Screw heater chassis to the wall using screws or bolts suited to the wall. Elbow Spout detail Page 5 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 6: Installation Procedures
Minimum - 0.7 bar, maximum - 7 bar. Warning: If pressure is likely to exceed 7 bar, a pressure limiting valve must be installed in the cold water supply line. Zip recommends a valve rated at 3.5 bar for this application. -
Page 7: Wall Mounting Template Dimensions
In order to help preserve our environment we ask that you dispose of this product correctly. Please contact Zip customer services for advice on 0845 602 4533 Page 7 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 8: Problem Solving
Warning- the water may be boiling - show extra care. 5. Test that in every instance the electrical resistance does not exceed 1 ohm. Page 8 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 9: Tap Operating Procedures
Tap Operation Safety feature. Zip Hydroboil Plus has a unique safety device designed to reduce the incidence of accidental operation of the tap.The tap can be “Locked” to prevent the Hydroboil Plus from dispensing hot water In order to “lock” the tap, ensure the safety button is protruding from the right hand side of the control panel and the... -
Page 10: Operational Procedure Settings
Low Light Mode is indicated by the Low Light symbol on the LCD. When the unit actually enters energy saver mode it is indicated by the Sleep Mode Indicator on the LCD. Page 10 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 11: Default Settings
In Normal operation mode the LCD will display as follows: Note: The BOILING WATER symbol is not displayed until the water reaches temperature. Page 11 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 12: Configuration Mode
CHANGE FILTER icon, the user must re-enter Configuration, set the Filter Expiration Time to OFF and return to Normal Operation. perational Page 12 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... - Page 13 If no action is sensed on the CSS’s for 20 seconds, the unit will revert to Normal Mode. After SAT OFF-TIME 2 pressing either CSS1 or CSS4 will revert the unit to Normal Mode. Page 13 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00...
-
Page 14: Spare Parts
Insulation Kit 5Litre 90737 Insulation Kit 7.5Litre 90130 Clips for Curled Tank Kit 90744 PCB Kit Hydroboil 2006 90214 Sensor Sleep Mode Page 14 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 15: Spare Parts
Spare Parts Page 15 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00... -
Page 16: Warranty And Contact Details
Furthermore, this warranty does not displace any statutory warranty, but, to the extent to which Zip is entitled to do so, the liability of Zip under any statutory warranty will be limited at Zip’s option to the replacement of the appliance...
