Installation must only be undertaken by a
competent person, familiar with unvented
electric water heaters.
The Zip Aquapoint must be installed in
accordance with these instructions and all
current legislation, codes of practice and
regulations governing the installation of
unvented hot water cylinders in force at
the time of installation.
AP3/10, AP3/15 Installation Instructions
Contents
Electrical
De-Installation
3
3
4
5
6
6
6
7
8
8
9
9
10
3
Advertisement
Table of Contents
Related Manuals for Zip Aquapoint III AP3/10
Summary of Contents for Zip Aquapoint III AP3/10
-
Page 1: Table Of Contents
Warranty Installation must only be undertaken by a competent person, familiar with unvented electric water heaters. The Zip Aquapoint must be installed in accordance with these instructions and all current legislation, codes of practice and regulations governing the installation of unvented hot water cylinders in force at the time of installation. -
Page 2: Specification
Sacrificial anode to provide added protection for vessel and element in aggressive water areas. Approvals: Zip Aquapoint III complies with LVD and EMC directives is CE endorsed and WRAS approved showing that it complies with the Water Fittings Regulations in England & Wales, the Water Byelaws 2000 in Scotland and the Water Regulations in Northern Ireland. -
Page 3: Dimensions
24.8 Special notices These instructions should guide you through the installation, maintenance and use of the Zip Aquapoint III, however, if you require any further information please call Zip Customer Service on 0870 608 8888. • The Zip Aquapoint is an unvented water heater designed for connection directly to the incoming mains water supply and can serve one or more outlets using conventional taps. -
Page 4: Installation
Requirements 1. These instructions must be read and fully understood before commencing the installation. If in doubt, or in need of further guidance, please call Zip Customer Service on 0870 608 8888. 2. Zip Aquapoint unvented water heaters must be installed by a competent installer, familiar with unvented electric water heaters. -
Page 5: Positioning
10. Valves and fittings must be of a type required by Water Supply Regulations Positioning 1. The Zip Aquapoint must be installed vertically. The connections should be at the top/rear of the unit. When facing the heater the hot supply (red) is to the left, and the cold feed (blue) to the right. - Page 6 For guidance please call Zip Customer Service on 0870 608 8888.
-
Page 7: Plumbing
1. Switch off the mains electrical supply before carrying out any work involving a live circuit or access to components that may be live. 2. The Zip Aquapoint is pre-wired with a length of 3 core cable suitable for connection to a mains 240v supply. Connection must be made in accordance with current IEE wiring regulations to a double pole isolating switch on a dedicated circuit or a double pole switched spur. -
Page 8: Commissioning
e. Remove the existing cable and pass the new cable through the grommet assembly f. Remake the cable connections and tighten the grommet locknut to ensure the cable is securely clamped g. Refasten the cover. 4. All internal wiring is factory mounted and should not be altered or modified. This appliance must be earthed. -
Page 9: Precautions
13. Pass these instructions to the person responsible for the building management Maintenance Precautions 1. The Zip Aquapoint is an unvented electric water heater and a competent person, familiar with unvented systems, should carry out all servicing and maintenance 2. Do not remove the cover whilst the unit is connected to the electrical supply 3. -
Page 10: Schedule
Schedule It is recommended that all key components of the heater should be inspected six monthly for continued safe and efficient operation. The inspection should be carried out by a competent person familiar with unvented systems and the components to be inspected should include the following: 1. -
Page 11: Fault Finding
Fault Finding NB All servicing and repairs must be undertaken by a competent person, familiar with unvented systems. Possible Cause Solution Fault Over temperature cut-out The thermostat has failed Reset. If the cut-out operates operates again isolate the unit and The thermostat is set at too contact the installer. - Page 12 Zip Heaters (UK) Ltd free of charge. This is providing that the failure is not due to misuse, abuse, condition of the water, frost or failure to follow installation instructions.
