INSTALLATION INSTRUCTIONS & USER MANUAL
ZIP
INLINE
Electronically controlled instantaneous water heaters
MODEL NUMBER:
ES3, ES4, ES6
1
INSTALLATION INSTRUCTIONS & USER MANUAL
TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
210011 V2.02 MAY 2018 -ZIP ES
WWW.ZIPWATER.CO.UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INLINE ES3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zip INLINE ES3

  • Page 1 INSTALLATION INSTRUCTIONS & USER MANUAL INLINE Electronically controlled instantaneous water heaters MODEL NUMBER: ES3, ES4, ES6 INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 2: Table Of Contents

    Please leave these instructions with the end user after installation. • To ensure you have a copy of the latest instructions visit www.zipwater.co.uk. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 3: Safety Information

    See Technical data, page 7. • The connecting cable must be adequately secured. • This appliance must be earthed at all times. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 4 • If the connection cable is damaged , it must be replaced with an original spare cable from Zip, by an authorised technician, in order to avoid any hazards.
  • Page 5: Cautions

    The appliance must not be used for any other purpose. • Incoming water temperature must not exceed that stated in Technical data. • The Zip InLine is intended for connection to mains supply only. In any other case please contact Zip on 0345 6 005 005 for advice.
  • Page 6: General Product Description

    APPROVALS Zip InLine ES3, ES4 and ES6 are VDE approved to the LVD and EMC directives and CE endorsed. Zip InLine ES3, ES4 and ES6 have been examined, tested and found when correctly fitted to comply with the requirements of the United Kingdom Water Regulations / Byelaws (Scotland). The products are listed under the WRAS (Water Regulations Advisory Scheme) Water Fittings and Materials Directory.
  • Page 7: Technical Data

    All data quoted at nominal supply voltage. Standard European voltage tolerances of -6% to +10% may be applied. A minimum water pressure of 0.2 MPa (2 bar) is recommended for optimum performance. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 8: Dimensions

    Temperature rise °C = (Nominal power rating (kW) x 14.3) Flow per minute (litres) DIMENSIONS 186mm 135mm 87mm INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 9: Spare Parts

    IN80910 Temperature sensor (not shown) ZL011 Aerator insert for ES3 and ES4 (not shown) ZL010 Aerator insert for ES6 (not shown) INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 10: Installation

    The electrical installation including earthing and cross bonding should comply with current IEE regulations and any Local Authority requirements. • Zip InLine water heaters must be installed according to the specification on the rating plate and the technical specifications. •...
  • Page 11: Installing The Appliance

    (Fig. A), tilt the appliance forward by max. 15° (Fig. B) and remove it upwards (Fig. C). INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 12 This insert fits commercially available sleeves with an M22 or M24 thread. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 13 Fig. 5 Fit Aerator insert Aerator insert Non-return valve Flow Control Valve Mains Supply Service Valve Rear Cable Entry INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 14: Electrical Connection / Wiring Diagram

    • Check everything is working as it should and the water temperature is achieving the desired temperature. If not follow the guide on pages 15/16. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 15: Removing The Cover

    Note Adding cold water wastes the energy used to heat it! This unit is not intended for use with a ‘thermostatic mixing valve’or tap. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 16 COMMISSIONING Water too cold May only be carried out by an authorised technician, call Zip on 0345 6 005 005. Remove the cover (see Fig. 7), undo the hood screw underneath and remove the hood • Increase the temperature by turning the potentiometer clockwise until the desired temperature is achieved.
  • Page 17: Maintenance & Cleaning

    • With the debris cleaned out, screw the regulator back into the tap. Hand tightening should be adequate. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 18: Repairs

    Repairs should only be carried out by competent persons familiar with electric instantaneous water heaters. • All service work should be performed by an authorized Zip service engineer – for details of the full range of services available call Zip on 0345 6 005 005. •...
  • Page 19: Fault Finding

    (authorised technician only) If the connection cable is damaged, it must be replaced with an original spare cable from Zip by an authorised technician in order to avoid any hazards. If you cannot rectify the fault with the aid of the troubleshooting table, please contact Zip customer service on 0345 6 005 005.
  • Page 20: End Of Life Disposal

    In order to preserve our environment we ask that you dispose of this product correctly. Please contact Zip Customer Service for advice on 0345 6 005 005. INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES...
  • Page 21: Warranty

    Furthermore, this warranty does not displace any statutory warranty, but, to the extent to which Zip is entitled to do so, the liability of Zip under any statutory warranty will be limited at Zip’s option to the replacement of the appliance or supply of equivalent appliance, the payment of the cost of replacing the appliance or acquiring an equivalent appliance, or the payment of the cost of having the appliance repaired or the repair of the appliance.
  • Page 22 NOTES INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 23 NOTES INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
  • Page 24: Contact Details

    Zip Water UK 14 Bertie Ward Way, Dereham, Norfolk NR19 1TE 0345 6 005 005 sales@zipindustries.co.uk www.zipwater.co.uk 9120-15038 INSTALLATION INSTRUCTIONS & USER MANUAL TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK 210011 V2.02 MAY 2018 -ZIP ES WWW.ZIPWATER.CO.UK...
