Zip Aquapoint III AP3/30 Installation Instructions Manual
Hide thumbs
Also See for Aquapoint III AP3/30:
Advertisement
Quick Links
Contents
Specification
Performance
Installation must only be undertaken by a
competent person holding a current Registered
Operative Identity card for the installation of
unvented domestic hot water storage systems
issued by an accredited body.
The Zip Aquapoint must be installed in
accordance with these instructions and all
current legislation, codes of practice and
regulations governing the installation of
unvented hot water cylinders in force at the
time of installation.
1
AP3/30, AP3/50, AP3/80, AP3/100 Installation Instructions
2
2
3
3-4
4-6
7-8
8
9
9-10
10-11
11
12
13
13
14
Specification
Product:
Zip Aquapoint III
Type:
Direct unvented
Capacity:
30 litre, 50 litre, 80 litre, 100 litre
Loading:
3.0kW/230v~
Fuse Rating:
15A
Thermostat:
Adjustable 25ºC to 75ºC
Thermal cut-out: Manually re-settable set to 84+0/-5ºC
Water vessel:
Glass enamelled steel tested to 13 bar. Maximum working
pressure 6 bar
Insulation:
High performance foam insulation
Controls:
Pressure reducing valve and line strainer set to 3.5 bar
Expansion relief and single check valve set to 6 bar
Pressure and temperature relief valve set to 7 bar and 90ºC
External expansion vessel pre-charged to 3.5 bar
Expansion vessel capacity: 5 litre AP3/30, AP3/50
Approvals:
Zip Aquapoint III complies with LVD and EMC directives and
is CE endorsed. Zip Aquapoint III has been examined,
tested and found, when correctly fitted, to comply with the
requirements of the United Kingdom Water Regulations/
Byelaws (Scotland). The product, therefore, is listed under
the WRAS (Water Regulations Advisory Scheme) Water
Fitting and Materials Directory.
Performance
Size
Model
30 litre
AP3/30
50 litre
AP3/50
80 litre
AP3/80
100 litre
AP3/100
8 litre AP3/80, AP3/100
Heat up time
Re-heat time
(15° to 65ºC)
(70% vol.)
37mins
23mins
58mins
38mins
88mins
58mins
110mins
72mins
2
