- Page 1 ® XTENDEX Series ST-C6USB4K-HDBT 4K HDMI Extender over HDBase-T with USB and RS232 Installation and Operation Manual MAN278 Rev Date 1/3/2020...
- Page 2 Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................2 Preparation for Installation .............................. 2 Installation ..................................3 RS232 Cable Pinout ..............................5 VESA Mounting Bracket ............................. 5 Interconnection Cable Wiring Method ..........................6 Troubleshooting................................7 Technical Specifications..............................7 Warranty Information............................... 8... -
Page 4: Introduction
NTI 4K HDMI EXTENDER OVER HDBASE-T INTRODUCTION The XTENDEX® 4K HDMI Extender over HDBase-T with USB and RS232 transmits uncompressed digital 4Kx2K HDMI signal, USB and RS232 up to 328 feet over a single CAT6/7 cable using HDBase-T technology. Each extender consists of a local unit that connects to a computer and a remote unit that connects to a UHD HDMI display and USB 2.0 device. -
Page 5: Materials
Use CAT6/6a/7 (CATx) straight through cables for TIA/EIA 568B wiring terminated with standard RJ45 connectors. Cables can be purchased from Network Technologies Inc by calling (800) 742-8324 (800-RGB-TECH) in the US and Canada or (330) 562-7070 (worldwide). Hardware Requirements ... -
Page 6: Installation
NTI 4K HDMI EXTENDER OVER HDBASE-T INSTALLATION 1. Connect a CAT6/6a/7 cable between the "HDBT OUT" on the Transmitter and the "HDBT IN" on the Receiver. 2. Connect the Transmitter to the video source with either a HDMI to HDMI cable, or HDMI to DVI (DVI video source) cable. 3. - Page 7 NTI 4K HDMI EXTENDER OVER HDBASE-T 5. Connect the Receiver to the extended display device with either a HDMI to HDMI cable, or HDMI to DVI cable (required if you have a DVI video source). Note: If your display device is DVI only, the video source must also be DVI. 6.
-
Page 8: Rs232 Cable Pinout
NTI 4K HDMI EXTENDER OVER HDBASE-T RS232 Cable Pinout If an RS232 Cable is used, the following connections need to be made; DB9F Pins Transmitter Signal DB9M Pins Receiver Signal (Connect at Terminal (Connect to Terminal PC (DTE )) Block device (DCE)) Block TxD Out... -
Page 9: Interconnection Cable Wiring Method
NTI 4K HDMI EXTENDER OVER HDBASE-T INTERCONNECTION CABLE WIRING METHOD The connection cable between the remote and local is terminated with RJ45 connectors and must be wired according to the EIA/TIA 568 B industry standard. Wiring is as per the table and drawing below. Pair 3 Pair 2 Pair 1... -
Page 10: Troubleshooting
NTI 4K HDMI EXTENDER OVER HDBASE-T TROUBLESHOOTING Make sure power is connected (blue LED is ON) Display has a black screen Make sure all cables are firmly connected at the transmitter, receiver, and the devices Make sure video source and display are powered ON and fully booted ... -
Page 11: Warranty Information
NTI 4K HDMI EXTENDER OVER HDBASE-T WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com information regarding repairs and/or returns.
