Introduction Introduction The XTENDEX Series ST-C5V-600 Video Extender is designed to enable one CPU to be viewed by two monitors, one local and one remote. The remote monitor can be located as much as 600 feet away from a CPU via Category 5 unshielded twisted-pair cable.
Features and Functions Features and Functions 1. Yellow LED- power indicator- illuminates when power has been supplied to the unit 2. Cat 5- RJ45 female- for connecting the CAT 5 cable 3. Video Connector- 15HD female- for connecting the local user's monitor 4.
Preparation for Installation Preparation for Installation • Locations should be chosen for the monitors that also have space to connect the Remote and Local Units within the distance provided by the cables. If extension cables are needed, contact NTI for the cables required.
Note: If an RJ45 wall outlet is being used, connect the other end of the extension cable to the RJ45 wall outlet. WARNING: Never connect the ST-C5V-600 Extender to an ethernet card, ethernet router, hub or switch or other ethernet RJ45 connector of an ethernet device. Damage to devices connected...
Note: If an RJ45 wall outlet is being used, connect the other end of the extension cable to the RJ45 wall outlet. WARNING: Never connect the ST-C5V-600 Extender to an ethernet card, ethernet router, hub or switch or other ethernet RJ45 connector of an ethernet device. Damage to devices connected...
Plug-in and Boot Up Plug-in and Boot Up 1. Plug the power cord from each monitor into a power outlet. Connect the power connector from the AC adapter to the 9VDC port on the Remote Unit. Make sure the power connector goes into the port all the way. Plug the AC adapter into a power outlet.
Note: When the cable is longer than 300 feet some colored lines can be seen at the black-to-white transitions. This is a normal behavior and is caused by the different twisting rates of each pair of wires in the CAT5 cable. Figure 5- Buttons for video quality adjustment Technical Specifications Technical Specifications...
Troubleshooting Troubleshooting Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise.
Page 12
Graphics Card Name and Model _______________ • • BIOS Mfr._______________________ Operating Video Resolution ___________________ 5. Make and Model Number of any other equipment connected between the monitor and the CPU. __________________________________________________________________________ ST-C5V-600 ST-C5V-600 REMOTE UNIT LOCAL UNIT SERIAL NO: SERIAL NO:___________ DATE:...
