- Page 1 ® XTENDEX Series ST-C5USBD-250 250 FOOT DVI and USB Extender via CAT5e/6 Installation and Operation Manual MAN087 Rev Date 10/22/2009...
- Page 2 XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 2009 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................1 Features and Functions..............................2 Installation ..................................3 Connecting The Local Unit ............................3 Connecting The Remote Unit ............................4 Operating Instructions ..............................5 Interconnection Cable Wiring Method ..........................5 Technical Specifications..............................6 Troubleshooting................................ -
Page 4: Introduction
INTRODUCTION The ST-C5USBD-250 (XTENDEX) USB Extender with DVI Video extends four USB devices and a single link DVI-D monitor up to 250 feet via two CAT5e/6/7 solid UTP cables. Each USB extender consists of a Local Unit that connects to a computer, and a Remote Unit that connects to four USB devices and a monitor. -
Page 5: Features And Functions
NTI 250 FOOT USB AND DVI VIDEO EXTENDER FEATURES AND FUNCTIONS ST-C5USBD-250 LOCAL UNIT FRONT VIEW REAR VIEW ST-C5USBD-250 REMOTE UNIT FRONT VIEW REAR VIEW 1. DVI Video In- DVI Female- for connecting cable from DVI video source 2. Power Connector- for connecting AC adapter 3. -
Page 6: Installation
1. Connect the Local Unit to the computer using an A-B USB cable. Connect the Type A connector to the computer and the Type B connector end to the Local Unit at “USB CPU”. 2. Connect the Local Unit to the DVI-D port on the computer using a male-to-male single-link DVI cable. ST-C5USBD-250 LOCAL UNIT (Front View) Mating Face of... -
Page 7: Connecting The Remote Unit
“USB CATx” to “USB CATx” ). Once connected check that the Power LED on both receiver and transmitter is ON and the “Tx/Rx” LEDs are both flashing, indicating that communication exists between the two units. ST-C5USBD-250 Remote Unit (Front View) -
Page 8: Operating Instructions
NTI 250 FOOT USB AND DVI VIDEO EXTENDER OPERATING INSTRUCTIONS Once installation is completed verify that the power is present at all devices in the system. If the computer was ON during the set up it might be necessary to reboot the computer. The display should react as if it were directly connected to the computer. The USB peripheral devices should be ready for use. -
Page 9: Technical Specifications
5.5x3.5x.1 TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise. -
Page 10: Warranty Information
The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com for information regarding repairs and/or returns. A return authorization number is required for all repairs/returns. PRODUCT: ST-C5USBD-250 SERIAL NO.: DATE: INSPECTED BY: MAN087 Rev.
