- Page 1 NETWORK 1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Aurora, OH 44202 Fax:330-562-1999 INCORPORATED www.networktechinc.com XTENDEX Series ST-C5KVM Universal KVM Extender Installation and Operation Manual MAN056 Rev Date 07/24/2006...
- Page 2 Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................1 Preparation for Installation .............................. 2 Installation ..................................3 The Local Unit................................3 The Remote Unit................................4 Plug-in and Boot Up..............................4 Video Quality ................................... 5 Jumper Settings................................5 Technical Specifications..............................6 Interconnection Cable Wiring Method ..........................6 Troubleshooting................................ -
Page 4: Introduction
INTRODUCTION The ST-C5KVM CAT5 Extender is designed to enable the relocation of a computer monitor, keyboard, and mouse from a computer or NTI KVM switch by as much as 1000 feet while keeping a second monitor local to the computer is so desired. It is extremely simple to install and has been thoroughly tested to insure reliable performance. -
Page 5: Preparation For Installation
NTI XTENDEX KVM EXTENDER PREPARATION FOR INSTALLATION • A location should be chosen for the monitor, mouse, and keyboard that also has space to mount the Remote Unit within the distance provided for by the cables from the monitor, mouse, and keyboard. If extension cables are needed, contact NTI for the cables required. -
Page 6: Installation
Two different Keyboard/Mouse cables have been provided, for the two possible plug configurations compatible with the NTI ST-C5KVM CAT5 Extender, depending on what style of computer the Extender is being connected to; VKTINT-3-MM for a PC or SKTINT-3-MM for a SUN. -
Page 7: The Remote Unit
RJ45 wall outlet. ) When properly inserted the CAT5 cable end should snap into place. WARNING: Never connect the ST-C5KVM Extender to an Ethernet card, Ethernet router, hub or switch or other Ethernet RJ45 connector of an Ethernet device. Damage to devices connected to the Ethernet may result. -
Page 8: Video Quality
NTI XTENDEX KVM EXTENDER VIDEO QUALITY Video quality adjustment is done automatically to assure the image is as clear as possible. Note: When the cable is longer than 400 feet some colored lines can be seen at the black-to-white transitions. This is a normal behavior and is caused by the different twisting rates of each pair of wires in the CAT5 cable. -
Page 9: Technical Specifications
NTI XTENDEX KVM EXTENDER TECHNICAL SPECIFICATIONS Maximum Resolution 1280 x 1024 - up to 1000 feet (refresh frequency 60Hz) 1600 x 1200 - up to 600 feet 1900 x 1200 - up to 400 feet Video Compatibility SVGA, XGA, VGA Video Quality Adjustment Automatic, for up to 1000 feet of CAT5 cable Video Coupling... -
Page 10: Troubleshooting
NTI XTENDEX KVM EXTENDER TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise. -
Page 11: Warranty Information
The warranty period on this product (parts and labor) is one (1) year from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com for information regarding repairs and/or returns. A return authorization number is required for all repairs/returns. ST-C5KVM ST-C5KVM REMOTE UNIT LOCAL UNIT...
