- Page 1 1”AIR IMPACT WRENCH MODEL NO: CAT154 PART NO: 3120168 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0317...
-
Page 2: Specification
INTRODUCTION Thank you for purchasing this CLARKE Impact Wrench. Please read all of the safety and operating instructions carefully before using this product. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 4 • Moving to another work area. • Passing the tool to another person. 13. Never use the tool if it is defective or operating abnormally. 14. This tool should be serviced at regular intervals by qualified personnel. 15. Avoid damaging the tool by applying excessive force. 16.
-
Page 5: Transport And Storage
TRANSPORT & STORAGE 1. Never carry the wrench by the air hose. 2. Never carry the wrench with your finger on the trigger. 3. When not in use the wrench should be disconnected from the air supply and stored in a dry place out of reach of children. 4. -
Page 6: Compressed Air Requirements
• A typical air line layout is shown above. If an automatic in-line filter/ regulator is used, it will keep the tool in good condition, but should be regularly checked and topped up with oil. clarke airline oil should be used, and the lubricator adjusted to approx 2 drops per minute. -
Page 7: Before Use
2. Remove the plastic blanking plug from the air inlet connection. 3. Pour 2-3 drops of Clarke airline oil into the oil filling port shown. This should be done regardless of whether or not a lubricated air supply is to be used. -
Page 8: Operation
OPERATION FITTING AN IMPACT SOCKET WARNING: NEVER USE STANDARD SOCKETS. THESE MAY SHATTER WITH SERIOUS CONSEQUENCES. ONLY USE IMPACT SOCKETS DESIGNED FOR USE WITH IMPACT TOOLS. CAUTION: ALWAYS TAKE CARE TO USE THE CORRECT SIZE SOCKET FOR BOLTS AND NUTS. AN INCORRECT SOCKET WILL CAUSE DAMAGE TO THE BOLT OR NUT. -
Page 9: Operating The Impact Wrench
OPERATING THE IMPACT WRENCH 1. Locate the socket over the nut to be tightened or loosened. 2. Squeeze the trigger to start the wrench. 3. Release the trigger switch to stop the wrench. • The anvil will continue to rotate very briefly after the trigger has been released. -
Page 10: Tightening A Nut
3. For lubricating the air motor, an air line lubricator should be used, (containing Clarke Air Line Oil). If this is not possible, run a few drops of oil through the tool before use. It may be entered into the tool air inlet, (ensuring the strainer is clear), or into the hose at the nearest connection to the air supply. - Page 11 4. Pour a few drops of Clarke air-line oil, into the tool air inlet. This should be carried out regardless of whether or not an in-line oiler is used. If an in-line oiler is not used, this procedure should be repeated after every two to three hours of use, or at the start of the working day.
-
Page 12: Troubleshooting
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. Store the tool safely in its box in a dry, secure environment. -
Page 13: Parts List
A wide range of accessories is available including filter/regulators, lubricators, high-pressure hoses (5 to 50 metres) etc. Contact your Clarke dealer for further information or the Clarke International Service Department. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
