- Page 1 ” ” (20mm) (20mm) HEAVY DUTY IMPACT WRENCH HEAVY DUTY IMPACT WRENCH MODEL - CAT 48 OPERATING & MAINTENANCE INSTRUCTIONS 0805...
- Page 2 HAND-ARM VIBRATION Employers are advised to refer to the HSE publication “Guide for Employers”. All hand held power tools vibrate to some extent, and this vibration is transmitted to the operator via the handle, or hand used to steady the tool. Vibration from about 2 to 1500 herz is potentially damaging and is most hazardous in the range from about 5 to 20 herz.
- Page 3 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
- Page 4 SAFETY PRECAUTIONS IMPORTANT Failure to follow these precautions could result in personal injury, and/or damage to property. ALWAYS wear BS approved impact resistant safety goggles. (Eye glasses are NOT safety glasses). ALWAYS wear face or dust mask (where dust is created). ALWAYS wear BS approved Ear Defenders, as considerable noise is generated, depending upon application.
- Page 5 AIR SUPPLY Tools of this type, operate on a wide range of air pressures. It is recommended that air pressure to this tool does not exceed 90 PSI, at the tool when running. Higher pressure and unclean air, will shorten the tools’ life because of faster wear, and could be a safety hazard.
- Page 6 (SAE30). For lubricating the air motor, an air line lubricator should be used, with Clarke Air Line Oil, adjusted to 2 drops per minute. If this is not possible, run a few drops of oil through the tool.
- Page 7 PARTS LIST Item Description Part No. Item Description Part No. Protecting Rubber 28-0030 Rear Rubber 28-0031 Seal 00-4205 Washer 00-1802 Housing 28-0001 O-ring 00-4111 Screw 00-0614 Valve Sleeve 28-0002 Anvil Bushing 28-0014 Reverse Valve 28-0003 Anvil Collar 28-0016 Rear Gasket 28-0027 O-ring 00-4118...
