  • Page 1 H.265 Network Cameras User Manual Ver. 1.0...
  • Page 2: All Rights Reserved © Surveon Technology 2019

    Furthermore, Surveon Technology reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation to notify any person of such revisions or changes.
  • Page 3: Revision History

    Revision History Version Description Date Initial release August 2019...
  • Page 4: Disclaimer

    Disclaimer CAUTION! The default password is used for your first login. To ensure account security, please change the password after your first login. You are recommended to set a strong password (no less than eight characters). To the maximum extent permitted by applicable law, the product described, with its hardware, ...
  • Page 5: Table Of Contents

    All Rights Reserved © Surveon Technology 2019 · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·...
  • Page 6: Chapter 1. Overview

    Chapter 1. Overview Adopting a small yet robust 3-axis gimbal design, the usability of CAM1471H2-2 H.265 IR Micro Dome IP Camera is highly enhanced. Besides, the lens can be adjusted to desired angle, so even when the camera has to be installed at unfavorable position, ideal field of view can be captured by repositioning the lens.
  • Page 7 CAM1471H2-5 H.265 IR Micro Dome IP Camera Indoor / Outdoor (with Cable) Self-tapping screws (x3) Plastic Anchors (x3) Security Torx Quick Guide NOTE: To use an external power supply, please contact the camera manufacturer to confirm that the power supply uses the same power specifications as the camera. The power supply must comply with the LPS requirements.
  • Page 8: Dimensions

    1.3 Dimensions The dimensions of the camera are shown below. Indoor Outdoor 1.4 Connectors (Indoor Only) The diagram below shows the default button, microSD card slot and various connectors of the camera. Definition of each connector is given as follows.
  • Page 9 Connector Definition Remarks RJ-45 Network and PoE connections DC 12V Power Power (DC 12V) connection Press the button with a proper Default Button tool for at least 20 seconds to restore the system. Alarm Out Alarm connection Alarm Out #Do NOT connect external power Alarm In + supply to the...
  • Page 10: Function Cable Definition (Outdoor Only)

    1.5 Function Cable Definition (Outdoor Only) Connector Definition Remarks RJ-45 Network and PoE connections DC 12V Power Jack Power connection (DC 12V) Audio In (Line Pink Two-way Audio I/O audio Audio transmission (Line Out) Alarm Alarm In – Alarm In + connection Alarm Out –...
  • Page 11: Chapter 2. Camera Cabling

    Chapter 2. Camera Cabling Before users connect cables, make sure that all cables and the power adaptor are placed in dry and well-waterproofed environments, e.g. waterproof boxes. The purpose is to prevent moisture accumulation inside the camera and moisture penetration into cables, which might lead to camera breakdown.
  • Page 12 Step 1: Loosen the two security screws on the camera with the supplied security torx and open the dome cover. Step 2: Place the camera at the installation location. Mark the position of the two screw holes indicated in the right figure on the ceiling/wall. Then draw a line along the concave edge of the camera to indicate the cable position.
  • Page 13: Chapter 3. System Requirements

    Chapter 3. System Requirements To perform the IP camera via web browser, please ensure the PC is in good network connection, and meet system requirements as described below. Items System Requirement Minimum : 1. Intel® CoreTM i5-2430M @ 2.4 GHz Personal 2.
  • Page 14: Chapter 4. Access Camera

    Chapter 4. Access Camera For initial access to the IP camera, users can search the camera through the installer program: DeviceSearch.exe. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2:After its window appears, click on the <Device Search> button on the top. All the finding IP devices will be listed in the page.
  • Page 15 Step 8: A prompt window requesting for default username and password will appear. Enter the default username and password shown below to login to the camera. Login ID Password Admin 1234 NOTE: ID and password are case sensitive. NOTE: It is strongly recommended that administrator’s password be altered for the security concerns.
  • Page 16 Once the Viewer is successfully installed, the Home page of the IP camera will be able to correctly display as the figure below. NOTE: Please refer to the H.265 HDR IP Camera Menu Tree for more button function details.
  • Page 17: Chapter 5. Setup Video Resolution

    Chapter 5. Setup Video Resolution Users can setup video resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default value of video resolution is as below. H.265/H.264- 2688 x 1512 (30/25 fps) + H.264- 800 x 600 (30/25 fps)
  • Page 18: Chapter 6. Configuration Files Export / Import

    Chapter 6. Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera.
  • Page 19: Chapter 7. Tech Support Information

    Chapter 7. Tech Support Information This chapter will introduce how to delete previously-installed Viewer in the PC and how to setup the Internet security. 7.1 Delete the Existing DCViewer For users who have installed the DCViewer in the PC previously, please first remove the existing DCViewer from the PC before accessing to the IP camera.
  • Page 20 Step 3:Under <ActiveX controls and plug-ins>, set ALL items (as listed below) to <Enable> or <Prompt>. Please note that the items vary by IE version. ActiveX controls and plug-ins settings: 1. Binary and script behaviors. 2. Download signed ActiveX controls. 3.
