5.1
Board Schematics
This section contains the following schematics:
Board Diagram - Schematic Top Level
Power supply
AT91SAM9RL Microcontroller
EBI Memory
Serial Memory
Audio AC97
Serial Interface
TFT LCD display
Expansion connectors
AT91SAM9RL-EK Evaluation Board User Guide
Section 5
Schematics
5-1
6325A–ATARM–08-Jan-08
