DOREL ASIA
WINGBACK HEADBOARD WITH NAILHEADS
Model No:
TG3878
UPC CODE:
0-65857-15970-7
DPCI#:
242-19-1185
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia TG3878
Summary of Contents for Dorel Asia TG3878
- Page 1 DOREL ASIA WINGBACK HEADBOARD WITH NAILHEADS Model No: TG3878 UPC CODE: 0-65857-15970-7 DPCI#: 242-19-1185 Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our customer service department.
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. - Page 3 WINGBACK HEADBOARD WITH NAILHEADS TG3878 HARDWARE LIST Ø5/16" X 50mm Ø19mm Ø12.5mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 6 PCS 10 PCS 10 PCS Ø5/16" X 70mm Ø16mm Ø4mm HEX SOCKET HEAD BOLT FLAT WASHER SCREW 4 PCS...
-
Page 4: Parts List
WINGBACK HEADBOARD WITH NAILHEADS TG3878 PARTS LIST HEADBOARD BODY HEADBOARD WING 1 PC 2 PCS FOOT 4 PCS - 2 -... - Page 5 WINGBACK HEADBOARD WITH NAILHEADS TG3878 STEP 1: Place all parts on a clean, smooth surface. Pull back the fabric lining underneath headboard body (A). Attach the headboard wings (B) to the headboard body (A) with flat washers (H2), spring washers (H3) and hex socket head bolts (H1). Use Allen Key (H10) to tighten the bolts.
- Page 6 WINGBACK HEADBOARD WITH NAILHEADS TG3878 STEP 2: Attach the feet (C) to the headboard body (A) with flat washers (H2) and hex socket head bolts (H4). Use Allen Key (H10) to tighten the bolts. Attach the feet (C) to the headboard wings (B) with flat washers (H5) and screws (H6). Use a screwdriver (not included) to tighten the screws.
- Page 7 WINGBACK HEADBOARD WITH NAILHEADS TG3878 NOTE: THE BED FRAME IS NOT INCLUDED AND MUST BE PURCHASED SEPARATELY. THE FOLLOWING ILLUSTRATIONS ARE FOR REFERENCE ONLY. Attach the bed frame (purchased separately) to bed posts using bolts (H7), spring washers (H3), flat washers (H9) and nuts (H8). Use Allen Key (H10) to tighten bolts and use the open end wrench (H11) to tighten the nuts.
- Page 8 WINGBACK HEADBOARD WITH NAILHEADS TG3878 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury.
-
Page 9: Customer Service
MODEL #: TG3878 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819...
