6 Cleaning with easyDial
6.8 Workflow for Fully Automatic ConvoClean Oven Cleaning with Single-
Measure Dispensing
Prerequisites
The unit door must be closed.
■
A fully automatic ConvoClean oven cleaning profile must have been selected.
■
The cleaning profile must have been started.
■
Cleaning process
The user removes all food
1
Before the fully automatic ConvoClean oven clean‐
ing process (with single-measure dispensing)
starts, all food needs to be removed from the oven
cavity. The C-Dial will light up with a solid green
light.
The unit prompts the user to open the unit door
An acoustic signal asking for the food to be re‐
moved from the unit will be emitted and the 'Open
unit door' prompt indicator will light up at the same
time.
Food taken out
2
While the user checks to make sure that all food
has been removed, the 'Close unit door' indicator
will light up. The C-Dial will light up with a solid yel‐
low light.
1st cleaning stage
3
Immediately after the unit door is closed, the 1st
cleaning stage (soaking stage) of the fully automat‐
ic ConvoClean oven cleaning process (with single-
measure dispensing) will start. The display will
show the remaining cleaning duration. The C-Dial
will light up with a solid yellow light.
The unit prompts the user to add cleaning agent
4
Once the 1st cleaning stage is complete, an acous‐
tic signal will be emitted and the 'Open unit door'
and 'Out of cleaning agent' indicators will light up.
The user adds cleaning agent
5
While cleaning agent is being added, the 'Close
unit door' and 'Out of cleaning agent' indicators will
light up. The system will also display the number of
bottles required. The C-Dial will light up with a solid
yellow light.
