3 easyDial Layout

3 easyDial Layout
Purpose of this section
The controls on your combi oven include a series of buttons and a rotary encoder called the
Convotherm-Dial (C-Dial). These buttons, together with the C-Dial and the unit's displays, can be used
to select and use all of the unit's functions.
This section provides an overview of the unit's easyDial user interface and goes over the functions be‐
hind the various buttons, displays, and the C-Dial.
3.1 easyDial Layout at a Glance
Used to select an operating mode
Please refer to page 12
Used to enter and display the cooking temperature
Please refer to page 12
Used to enter and display the cooking time or the internal
temperature
Please refer to page 12
Used to select cooking functions (ACS+ extra functions)
Please refer to page 13
Prompt indicators
Please refer to page 14
Programmbereich
Siehe page 15
C-Dial (control unit and status indicator)
Please refer to page 16
