3 easyDial Layout
3.8 C-Dial Functions
Turning the C-Dial Used to select settings
Quickly pressing
■
the C-Dial
■
Please refer to page 27
Please refer to page 44
Pressing and hold‐ Used to access the 'Settings'
ing down the C-Dial
Please refer to page 52
Green C-Dial light Solid light
Flashing light
Yellow C-Dial light Solid light
Flashing light
Red C-Dial light Solid light
Blue C-Dial light Solid light
Flashing light
Used to confirm settings
Used to start and end processes
Door closed and unit ready for operation
■
Sequence done
■
Program slot in 'Cookbook' is free
■
Operator prompt
Unit door open
■
'Pre-heating' or 'Cool down' in progress
■
Cleaning sequence in progress
■
Program slot in 'Cookbook' is free
■
Warning asking the operator to be careful
Cooking sequence in progress
USB stick plugged in and 'Cookbook' selec‐
ted
Data transfer in progress
