Sunny SF-RW5727 User Manual

Full motion rowing machine with aluminum slide rail
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FULL MOTION ROWING MACHINE
WITH ALUMINUM SLIDE RAIL
SF-RW5727

USER MANUAL

IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-RW5727 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunny SF-RW5727

Summary of Contents for Sunny SF-RW5727

  • Page 1: User Manual

    FULL MOTION ROWING MACHINE WITH ALUMINUM SLIDE RAIL SF-RW5727 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly. It is your responsibility to ensure that all users of the equipment are informed of all warnings and precautions.

  • Page 3: Exploded Drawing

    EXPLODED DRAWING HARDWARE PACKAGE 2PCS #54 φ10*65 2PCS M8*15 13PCS #53 M12*160 2PCS φ8 13PCS φ10 4PCS Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: ✓...

  • Page 4: Parts List

    PARTS LIST Description Specification Qty. Description Specification Qty. Front Stabilizer Pedal R Main Frame Cover Rear Support End Cap Armrest Limit Rotating Armrest Stopper Meter Support L200 Foam Grip Handlebar Meter L300 Handrail Support Link Wire Of Meter Seat Support Trunk Wire L750 Sensor...

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS STEP 1: Attach the Front Stabilizer (No. 1) to the Main Frame (No. 2) using 2 Screws (No. 43) and 2 Washers (No. 45). Tighten and secure with Allen Wrench (No. 14). STEP 2： Attach the Rear Support (No. 3) onto the Main Frame (No.
  • Page 6 STEP 4: Insert the Link Wire Of Meter (No. E) into the Meter Support (No. 5). Then attach the Meter (No. 34) onto the Meter Support (No. 5) using 2 Screws (No. 46) and 2 Washers (No. 47). Tighten with Allen Wrench (No.
  • Page 7 STEP 7: Attach the Handlebars (No. 6) into the Rotating Armrest (No. 4) using 2 Bolts (No. 54), 4 Washers (No. 52) and 2 Nuts (No. 55). Tighten and secure with Allen Wrench (No. 14) and Spanner (No. 17). STEP 8: Make sure the arrow on the Seat (No.

  • Page 8: Adjustment Guide

    ADJUSTMENT GUIDE ADJUSTING THE PEDALS The Pedal Straps (No. 48) can be adjusted to the user’s own foot/shoe size. Pull the Pedal Straps (No. 48) to adjust the degree of tightness. ADJUSTING THE RESISTANCE To adjust the tension level, turn the Adjustment Knob (C) on the Hydraulic Cylinder (No.

  • Page 9: Exercise Computer

    EXERCISE COMPUTER SPECIFICATIONS: TIME---------------------------------------------------00:00—99:59 MIN/SEC COUNT------------------------------------------------0—9999 TIMES CALORIES-------------------------------------------0—999.9 CAL REPS/MIN--------------------------------------------0—999 TIMES/MIN TOT. CNT---------------------------------------------0—9999 TIMES KEY FUNCTION MODE: Press MODE to select the desired display value. SELECT: Press the key for 4 seconds to have all function values reset (total reset). AUTO ON/OFF: If the machine is put into motion or the MODE button is pressed, the monitor will activate and will remain active unless there is no signal for approximately 4 minutes.
