1.2 Scope of delivery

6
4
not included
Fig. 1: Scope of delivery and overview
4 Lock 309X, not included in scope of
delivery
6 Outer fitting
7 Hexagonal nut
8 Inner fitting
9 Sleeve nut
10 Spring washer
11 Hexagonal nut
12 Battery block
13 Decorative housing
14 Countersunk screw
Page 20
Decorative plate set
496-1080050--35
optional
Lock
309X
Decorative plate set
496-1080050--35
optional
7 8
(3x)
12
9
10 11
(2x) (2x)
1
3
1
1
2
2
1
1
2
13
14
(2x)
D00396
02
