Replacing a drawer in base system/ expansion unit

Hide thumbs Also See for StorNext QD7000:

c. Place the drive on a flat, static-free surface and away from magnetic devices.

Attention:

Possible loss of data access – Magnetic fields can destroy all data on the drive and cause irreparable

damage to the drive circuitry. To avoid loss of data access and damage to the drives, always keep drives away from

magnetic devices.

6. Follow these steps to remove the drive drawer:

a. Locate the plastic release lever on each side of the drive drawer.

b. Open both release levers by pulling the latches toward you.

c. While holding both release levers, pull the drive drawer toward you.

d. Remove the drive drawer from the drive tray.

Drive drawer release lever

Replacing a Drive Drawer in a 60-Drive Tray
