WARNING: Ensure that the system time of the computer running the K-Link software
and the system time of the G210 have both been set to the correct time before
proceeding.
NOTE: To ensure a stable connection between K-Link and the G210, it is recommended that the
G210 be configured with a static IP address. Consult your IT department for IP configuration settings
specific to your network.
NOTE: After pressing "Start", the device connection window will disappear, and the main window will
appear. However, it can take up to 1 minute before any graph can be seen.
Measurement Section
The measurement section displays the measurements retrieved from the device every 30 seconds,
the connection status of the device, a setting to enable or disable email notifications if an alarm is
triggered, and an "Open Log" button to explore the folder containing the file where the logs are
being saved.
Alarm Display Section
The alarm section displays the status of the alarms. When an alarm is activated on the device, the
associated alarm in K-Link will change colour to red. When the alarm is no longer activated on the
device, the associated alarm in K-Link will change colour back to green. K-Link refreshes the alarms
every 5 seconds.
K-Link
10
33
