Section 6 - G210 InviCell Plus

G210 InviCell Plus supports external and independent movement and monitoring of the most critical
parameters regarding the performance of culture media, CO
pH measurement.
All external sensors are completely independent of the functions and controls in the G210 InviCell
Plus as they are connected to and powered by instruments independent of the G210 InviCell Plus.
CAUTION: Installations of external sensors must be performed by CooperSurgical or
by persons authorized by CooperSurgical only.
1
1 Connection for external CO
2 Connection for external pH monitoring (pH Online™)
3 Data connection for external thermometer and power
4 Power connection for external thermometer and power
External Sensors, pH / CO
The following external sensors can be used with the G210 InviCell Plus:
• External pH: OCTAX Log & Guard™ from MTG GmbH
•
External CO : OCTAX Log & Guard™ CO
2
GMP251 Carbon Dioxide Probe from Vaisala Oyj
These parts need to be purchased separately, directly from MTG GmbH or Vaisala Oyj.
An external CO connector for the GMP251 Carbon Dioxide Probe from Vaisala Oyj is enclosed.
2
Connectors can to be ordered separately.
• OCTAX Log & Guard™ CO
• GMP251 Carbon Dioxide Probe from Vaisala Oyj
2
3
Component
sensor
2
2
sensor from MTG
2
sensor from MTG
2
G210 InviCell Plus
concentration, temperature and
2
G210 InviCell Plus - back view
