DEMO MANUAL DC1723A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 2 C2, C9
2 1 C3
3 1 C10
4 1 R2
5 1 R4
6 1 R5
7 1 R6
8 1 R7
9 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 0 C4, C5, C8 (OPT)
3 0 C6 (OPT.)
4 0 C7 (OPT.)
5 0 R1, R3 (OPT.)
6 0 FB1 (OPT.)
7 0 L1 (OPT.)
Hardware-For Demo Board Only
1 8 E1-E8
2 2 JP1-JP2
3 1 XJP1-XJP2
4 1 Stencil
4
PART DESCRIPTION
CAP., X7R, 2.2µF, 100V, 10%, 1206
CAP., X5R, 100µF, 6.3V, 20%, 1210
CAP., X7R, 0.1µF, 10V, 10%, 0603
RES., CHIP, 0Ω, 1/10W, 0603
RES., CHIP, 93.1k, 1/10W, 1% 0603
RES., CHIP, 100k, 1/10W, 1% 0603
RES., CHIP, 97.6k, 1/10W, 1% 0603
RES., CHIP, 0Ω, 1/4W, 1% 1206
IC., MODULE REGULATOR, LTM8050EY BGA-70 LEAD
CAP., ELECTROLYTIC, 10µF, 100V
CAP., 0603
CAP., 1210
CAP., ALUM CAP.,
RES., CHIP, 0603
FERRITE BEAD, M TYPE
IND., 10µH
TESTPOINT, TURRET, 0.094" PBF
3 PIN 0.079" SINGLE ROW HEADER
SHUNT, 0.079" CENTER
MANUFACTURER/PART NUMBER
MURATA, GRM31CR72A225KA73
MURATA, GRM32ER60J107ME20L
AVX, 0603ZC104KAT2A
NIC, NRC06ZOTRF
VISHAY, CRCW060393K1FKEA
NIC, NRC06F1003TRF
VISHAY, CRCW060397K6FKEA
NIC, NRC12Z0TRF
LINEAR TECH., LTM8050EY
SUN ELECT., 100CE10BS
TAIYO YUDEN, FBMJ3216HS800T
VISHAY, IHLP-2525CZ-01
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN031PAEN-RC
SAMTEC, 2SN-BK-G
dc1723af
