Metra Electronics 95-8903S Installation Instructions Manual

Subaru legacy & outback 2010-up

INSTALLATION INSTRUCTIONS FOR PART 95-8903S

Subaru Legacy & Outback 2010-up

KIT FEATURES

• DDIN radio provision

• Stacked ISO radio provision

• Painted silver

KIT COMPONENTS

• A) DDIN Trim plate • B) DDIN Brackets

WIRING & ANTENNA CONNECTIONS (Sold Separately)

Wiring Harness:

• 70-8901 Subaru Harness 1990-Up

• 70-7552 Nissan Harness 2007-Up

Antenna Adapter:

• 40-SB10 Subaru Antenna Adapter 2005-Up

Panel Removal Tool • Phillips Screwdriver • Socket Wrench • Small Flat Blade Screwdriver

APPLICATIONS

(Non-navigation radios only)

95-8903S

TOOLS REQUIRED

METRA. THE WORLD'S BEST KITS.™

1-800-221-0932

metraonline.com

Table of Contents

Need help?

Do you have a question about the 95-8903S and is the answer not in the manual?

Page 1 INSTALLATION INSTRUCTIONS FOR PART 95-8903S APPLICATIONS Subaru Legacy & Outback 2010-up (Non-navigation radios only) 95-8903S KIT FEATURES • DDIN radio provision • Stacked ISO radio provision • Painted silver KIT COMPONENTS • A) DDIN Trim plate • B) DDIN Brackets WIRING &...
Page 2 95-8903S Table of Contents Dash Disassembly – 2010-up Subaru Legacy Kit Assembly – Double DIN/Stacked ISO DIN Head Unit Provision Caution Metra recommends disconnecting the negative battery terminal before beginning any installation. All accessories, switches, and especially air bag indicator lights must be plugged in before reconnecting the battery or cycling the ignition.
Page 3 95-8903S Dash Disassembly 1. Disconnect the negative battery terminal to prevent an accidental short circuit. 2. Unclip and remove the radio trim panel including the a/c vents. (Figure A) 3. Remove (4) Phillips screws securing the factory radio. Continued to kit assembly...
Page 4 Kit Assembly 95-8903S Double DIN/Stacked ISO DIN head unit provisions 1. Locate the factory wiring harness in the dash. Metra recommends using the proper mating adapter from Metra or AXXESS. Re-connect the negative battery terminal and test the unit for proper operation.
