- Page 1 INSIEME EVO 32 B/100-32 B/100 S EN USER MANUAL...
- Page 2 INSIEME EVO 32 B/100-32 B/100 S boiler. Please accept our renewed thanks for your purchase. Riello S.p.A. CONFORMITY INSIEME EVO 32 B/100-32 B/100 S boilers conform to the following directives: −...
-
Page 3: Table Of Contents
CONTENTS 1 GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 General Safety Information . -
Page 4: General Information
GENERAL INFORMATION GENERAL INFORMATION 1.2 Precautions The operation of any appliance that uses fuel, electrical power 1.1 General Safety Information and water demands that a number of fundamental safety pre- cautions be respected: This product must be installed by a legally qualified heat- Do not allow children or infirm persons to operate the sys- ing engineer. -
Page 5: Description Of The Appliance
(100°C). The sensor used to monitor this tem- chamber. perature is located on the body of the heat exchanger; Model INSIEME EVO 32 B/100 S (unlike model INSIEME EVO 32 − A minimum temperature thermostat that enables the B/100) has a sealed chamber. -
Page 6: System Layout
GENERAL INFORMATION 1.5 System layout INSIEME EVO 32 B/100 Fuel oil filter Control panel Boiler sensor socket Central heating circuit expansion vessel Capillary pressure gauge fitting Distribution manifold Central heating circuit safety valve Boiler drain cock Storage cylinder fill cock 10 Storage cylinder expansion vessel Storage cylinder inspection flange 12 Storage cylinder flange insulation... - Page 7 GENERAL INFORMATION INSIEME EVO 32 B/100 S Fuel oil filter Control panel Boiler sensor socket Central heating circuit expansion vessel Capillary pressure gauge fitting Distribution manifold Central heating circuit safety valve Boiler drain cock Storage cylinder fill cock 10 Storage cylinder expansion vessel...
-
