- Page 1 CONDENSING BOILERS 26 B - 26 BK 35 B - 35 BK INSTRUCTION FOR THE USER 26 BK 35 BK 26 B 35 B...
-
Page 2: Table Of Contents
CONTENTS General safety information Precautions Control panel Start-up Temporary shutdown Preparing for extended periods of disuse Cleaning Maintenance Useful information The following symbols are used in this manual: = Identifies actions that require caution and ade- quate preparation. = Identifies actions that you MUST NOT do This manual, Code 20042453 Rev. - Page 3 Technical Assistance Centres also stock any original spare parts that might be required. This instruction manual contains important instructions and precautions that must be observed to ensure the trouble-free installation and efficient functioning of your boiler. Please accept our renewed thanks for your purchase. Riello S.p.A. USER...
-
Page 4: General Safety Information
GENERAL SAFETY INFORMATION The operation of any appliance that uses electrical power demands that a number of fundamental safety precautions be respected. Do not allow children or Never pull, disconnect, or twist the electrical cables infirm persons to operate coming from the boiler even if it is disconnected the boiler unsupervised. -
Page 5: Control Panel
CONTROL PANEL INSIEME CONDENS 26 B - 35 B 1 - Function selector II On III On IIII Automatic mode (only active with temperature control kit installed) 2 - Boiler temperature gauge Displays the temperature of the central heating water. - Page 6 INSIEME CONDENS 26 BK - 35 BK 1 - Function selector II On III On IIII Automatic mode (only active with temperature control kit installed) 2 - Boiler temperature gauge Displays the temperature of the central heating water. Boiler control thermostat Allows you to set the temperature of the central heating water.
-
Page 7: Start-Up
START-UP Have r’s Technical Assistance Service start-up your boiler for the first time. Once this has been done, the boiler can be left to function automatically. Under certain circumstances, such as after long periods of disuse, the user may need to re-start it without involving the Technical Assistance Service. Before doing so, perform the following checks and operations: - Check that the fuel cock and heating system water cock are shut. - Page 8 On models 26 BK and 35 BK: - Turn the (I)Summer/(II)Winter selector to (II) Winter. 40 60 80 - Turn the function selector to ON (II) and make sure that the green power indicator lights. The burner should ignite and remain in operation until the temperature setpoint is reached.
- Page 9 If the problems persist, proceed as follows to make sure that the flue gas thermostat has not tripped. - Wait about 5 minutes, then remove the cover from the flue gas thermostat reset button (8) and push the button. - Wait for the burner to complete the entire start-up cycle again, up to the ignition of the flame.
-
Page 10: Temporary Shutdown
TEMPORARY SHUTDOWN If you are going away for a short period of time like a weekend or a short holiday, etc., and outdoor temperatu- res are going to remain above ZERO, proceed as follows: - Turn the function selector to OFF (I) and make sure that the green power indicator goes out. -
Page 11: Cleaning
CLEANING Use a cloth damped in soapy water to clean the boi- ler’s external panelling. To remove stubborn marks, use a cloth damped in a 50% mix of water and denatured alcohol or a suitable cleaning product. Wipe the boiler dry after cleaning it. The combustion chamber and flues must be cle- aned periodically by r’s Technical Assistance Service or by a qualified heating engineer. -
Page 12: Useful Information
USEFUL INFORMATION Seller: Installer: ....................................................................................................................Address Address ......................................................Tel. Tel............................................................Technical Assistance Service: ............................................Address ............................Tel............................... Date Work done Fuel oil supplier: ....................................................Address ............................Tel............................... Date Quantity supplied Date Quantity supplied Date... - Page 13 USER...
- Page 14 USER...
- Page 16 RIELLO S.p.A. 37045 Legnago (VR) Tel. 0442630111 - Fax 0442630371 - www.riello.it As part of the company’s ongoing commitment to perfecting its range of products, the appearance, dimensions, technical data, equipment and accessories may be subject to variation.
