2. Hardware Description

2.1 Front Panel
The Front Panel of the PoE Ethernet Switch Consists of Ethernet Ports. The LCD Display and LED indicators
are also located on the panel
LED indicator
LED
PWR
LNK/ACT
PoE
Color
Off: No Power supply.
Green
Light: Indicates the switch has power.
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
Orange
Blink: Indicates that the Switch is actively sending or
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
Green
Blink: Indicates that the Switch is actively sending or
receiving data over that port.
Off: No PoE powered device (PD) connected.
Light: There is a PoE PD connected to be port, which
Orange
Blink: Indicates port abnormal power supply.
Function
established at 10/100Mbps.
receiving data over that port.
established at 1000Mbps.
supply power successfully.
