- Page 1 EKI-2525 5-port 10/100Base-TX Industrial Unmanaged Ethernet Switch EKI-2528 8-port 10/100Base-TX Industrial Unmanaged Ethernet Switch User Manual...
- Page 2 The documentation and the software included with this product are copyrighted 2007 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 Because of Advantech s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 4 Step 2. Contact your distributor, sales representative, or Advantech’s customer service center for technical support if you need additional assistance. Please have the following information ready before you call: - Product name and serial number...
- Page 5 Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User' s Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4.
- Page 6 Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage. 1. To avoid electrical shock, always disconnect the power from your PC chassis before you work on it. Don' t touch any components on the CPU card or other cards while the PC is 2.
-
Page 7: Table Of Contents
Contents Chapter 1 Overview ........... 2 1.1 Introduction ............2 1.1.1 High-Speed Transmissions ....... 2 1.1.2 Dual Power Input ........2 1.1.3 Flexible Mounting........2 1.1.4 Advanced Protection......... 2 1.1.5 Wide Operating Temperature....2 1.1.6 Easy Troubleshooting ....... 2 1.2 Features............. 3 1.3 Specification ............ - Page 8 EKI-2525 & 2528 User Manual viii...
-
Page 9: Chapter 1 Overview
Overview Sections include: Introduction Features Specifications Packing List Safety Precaution Chapter1... -
Page 10: Introduction
Chapter 1 Overview 1.1 Introduction The EKI-2525/2528 is a cost-effective solution and meets the high reliability requirements demanded by industrial applications. 1.1.1 High-Speed Transmissions The EKI-2525/2528 includes a switch controller that can automatically sense transmission speeds (10/100 Mbps). The RJ-45 interface can also be auto-detected, so MDI or MDI-X is automatically selected and a crossover cable is not required. -
Page 11: Features
1.2 Features • Provides 5 x 10/100Base-TX (EKI-2525) or 8 x 10/100Base-TX (EKI-2528) Ethernet ports with RJ-45 connector • Supports full/half duplex flow control • Supports store and forward transmission • Supports auto-negotiation • Supports MDI/MDI-X auto crossover • Provides surge protection (EFT) 3,000 V for power line •... -
Page 12: Specification
Transmission Distance Up to 100 m Transmission Speed Up to 100 Mbps Interface Connectors 5 x RJ-45 (EKI-2525) 8 x RJ-45 (EKI-2528) 6-pin removable screw terminal (power) LED Indicators Unit: P1, P2, P-Fail TX port: Link/Active, Duplex/Collision Power Current Overload Protection 0.9A@12V... - Page 13 Certifications Safety UL, 60950-1, CAN/CSA-C22.2 No.60950 U.S.A.: FCC Part 15 CISPR 22 EU: EN55011, EN61000-6-4 EN55022, Class A, EN61000-3-2/3 EN55024 IEC61000-4-2/3/4/5/6/8/11/12 EN61000-6-2 Free Fall IEC60068-2-32 Shock IEC60068-2-27 Vibration IEC60068-2-6 Chapter1...
-
Page 14: Packing List
1.4 Packing List • 1 x EKI-2525/EKI-2528 Industrial Ethernet Switch • 1 x eAutomation Industrial Communication CD-ROM with software, and User manual • 2 x Wall Mounting Bracket and Screws • 1 x DIN-rail Mounting Bracket and Screws • 1 x EKI-2525/2528 Startup Manual •... -
Page 15: Chapter 2 Installation
Installation Sections include: LED Indicators Dimensions Mounting Network Connection Power Connection Chapter2... - Page 16 Chapter 2 Installation In this chapter, you will be given an overview of the EKI-2525/2528 hardware installation procedures. 2.1 LED Indicators There are few LEDs display the power status and network status located on the front panel of EKI-2525/2528, each of them has its own specific meaning as below table. Table 2.1: EKI-2525/2528 LED Definition Color Description...
-
Page 17: Dimensions (Units: Mm)
2.2 Dimensions (units: mm) Figure 2.1: Front View of EKI-2525/2528 Chapter2... - Page 18 Figure 2.2: Side View of EKI-2525/2528 EKI-2525 & 2528 User Manual...
- Page 19 Figure 2.3: Rear View of EKI-2525/2528 Chapter2...
- Page 20 Please refer to page 16 for pin assignment. Figure 2.4: Top View of EKI-2525/2528 EKI-2525 & 2528 User Manual...
-
Page 21: Mounting
2.3 Mounting The EKI-2525/2528 supports two mounting methods: DIN-rail & Wall. 2.3.1 Wall mounting EKI-2525/2528 can be wall-mounted by using the included mounting kit. Then, hang on the EKI-2525/2528 to the nails on the wall. First, use the screws included in the package to combine the EKI-2525/2528 and metal mounting kit. -
Page 22: Din-Rail Mounting
2.3.2 DIN-rail Mounting You can also mount EKI-2525/2528 on a standard DIN-rail by below steps. The DIN-rail kit is screwed on the industrial switch when out of factory. If the DIN-rail kit is not screwed on the industrial switch, please screw the DIN-rail kit on the switch first. First, hang the EKI-2525/2528 to the DIN-rail with angle of inclination. - Page 23 Then, let the device down straight to slide over the rail smoothly. See Figure 2.7 Figure 2.7: Installation to DIN-rail Step 2 Chapter2...
-
Page 24: Network Connection
2.4 Network Connection The EKI-2525 has 5 x RJ-45 ports or EKI-2528 has 8 x RJ-45 ports that support connection to 10 Mbps Ethernet, or 100 Mbps Fast Ethernet, and half or full duplex operation. EKI-2525/2528 can be connected to other hubs or switches through a twisted-pair straight through the cable or a crossover cable up to 100m long. -
Page 25: Chapter 3 Troubleshooting
Troubleshooting Chapter2... - Page 26 Chapter 3 Troubleshooting Power Input Verify that is using the right power cord/adapter (+12~48 V ), please don’t use the power adaptor with DC output voltage higher than 48V, or it will burn this converter down. Cable Select the proper UTP cable to construct user network. Please check that is using the right cable.
-
Page 27: Appendix A Pin Assignment & Wiring
Pin Assignment & Wiring Chapter2... - Page 28 Appendix A Pin Assignment & Wiring It is suggested to adopt ELA/TIA as the wiring of the RJ-45. Figure A.1: RJ-45 Pin Assignment Figure A.2: EIA/TIA-568B Figure A.2: EIA/TIA-568A EKI-2525 & 2528 User Manual...
