Advantech 8GE(PoE)+2GE+2G SFP User Manual page 5

Not only such visible on the basis of three generations in the second generation increases the color logo,
according to the menu button, switch mode, bandwidth display and warning, PD type, PSE power fine-tuning and
priority, PoE port switch control, LCD switch. Enhance the LCD viewing angles, smart fan control, language selection and
the function of the factory Settings, in turn, as shown in the figure below:
concretely.
3. Installation the Switch
This part describes how to install your Ethernet Switch and make connections to it .Please follow
the following instructions in avoid of incorrect installation causing device damage and security
threat.
 Before cleaning the switch, unplug the power plug of the switch first. Do not clean the switch with wet
cloth or liquid;
 Do not place the switch near water or any damp area. Prevent water or moisture from entering the
switch chassis;
 Do not place the switch on an unstable case or desk. The switch might be damaged severely in case of a
fall;
 Ensure proper ventilation of the equipment room and keep the ventilation vents of the switch free of
Obstruction;
 Make sure that the operating voltage is the same one labeled on the switch ;
 Do not open the chassis while the switch is operating or when electrical hazards are present to avoid
electrical shocks;
See the operation instructions of the screen
