Kramer VS-88UHD User Manual page 79

MTX-MODE
VMUTE
ROUTE
MTX-MODE
Functions
MTX-MODE
Set:
MTX-MODE?
Get:
Description
Set: Set auto-switch mode
Get : Get auto-switch mode
Response
~nn@MTX-MODESPoutput_id,modeCR
Parameters
output_id – 1 (OUT 1), 2 (OUT 2), 3 (OUT 3), 4 (OUT 4), 5 (OUT 5), 6 (OUT 6), 7 (OUT 7), 8 (OUT 8)
mode – 0 (Manual), 1 (Auto priority) 2 (Auto last connected)
Response Triggers
After execution, a response is sent to the com port from which the Set/Get was received.
After execution, a response is sent to all com ports if MTX-MODE was set by any other external control device
(button press, WEB, device menu and similar).
Notes
Not recommended for new devices.
K-Config Example
Set output to last connected:
"#MTX-MODE 1,2",0x0D
ROUTE
Functions
ROUTE
Set:
ROUTE?
Get:
Description
Set: Set layer routing
Get: Get layer routing
Response
~nn@ROUTESPlayer,dest,srcCR LF
Parameters
layer – 1 (Video), 2 (Audio)
dest – 1 (HDMI OUT 1), 2 (HDMI OUT 2), 3 (HDMI OUT 3), 4 (HDMI OUT 4), 5 (HDMI OUT 5),
6 (HDMI OUT 6), 7 (HDMI OUT 7), 8 (HDMI OUT 8), * (All outputs)
src – 1 (HDMI IN 1), 2 (HDMI IN 2), 3 (HDMI IN 3), 4 (HDMI IN 4), 5 (HDMI IN 5), 6 (HDMI IN 6),
7 (HDMI IN 7), 8 (HDMI IN 8), 0 (Output disconnected)
Notes
The get command identifies input switching on Step-in clients.
The set command is for remote input switching on Step-in clients (essentially via the web).
K-Config Examples
Route video HDMI IN 2 to video HDMI OUT 8:
"#ROUTE 1,8,2",0x0D
UHD Matrix Switcher – Protocol 3000
Set/get to auto-switch mode
Set/get video on output status
Set/get layer routing
Permission
End User
End User
Syntax
#MTX-MODESPoutput_id,modeCR
#MTX-MODE?SPoutput_idCR
Permission
End User
End User
Syntax
#ROUTESPlayer,dest,srcCR
#ROUTE?SPlayer,destCR
Kramer Electronics Ltd.
Transparency
Public
Public
Transparency
Public
Public
77
