Installation - Parts
XM Plural-Component
OEM Sprayer
For spraying two-component epoxy and urethane protective coatings
in non-hazardous locations.
For professional use only.
Important Safety Instructions
Read all warnings and instructions in this
manual and in related manuals before using
the equipment. Save all instructions.
See page 9 for model information.
See page 27 for maximum working pressure.
For patent information, see www.graco.com/patents
313292J
EN
