Summary of Contents for Graco XM Plural-Component
- Page 1 XM Plural-Component Sprayers High-Pressure Equipment for Protective Coatings...
- Page 2 Advanced technology and accurate ratio control Graco XM Plural-Component Sprayers are designed to spray the toughest plural-component materials, with the assurance that you’re spraying accurately and on-ratio. Ideally suited for marine, bridge, rail and wind energy applications, each Graco XM is fully configurable –...
- Page 3 More flexibility means more affordability With Graco XM Plural-Component Sprayers, you have the flexibility to select the essential equipment on your system – no more, no less – to complete your jobs accurately and reliably. If your application does not require heaters, feed pumps or hoppers, this flexibility may provide you with a lower cost option.
- Page 4 Performance You Can Trust Advanced technology that boosts your productivity Packed with features Whether your application requires a basic machine or one that is fully loaded, the Graco XM provides the technology and performance you need to get the job done faster and more efficiently than ever before. Precise mixing and ratio assurance Material mixing reaches a new level of precision due to new dosing technology.
-
Page 5: Technical Specifications
Technical Specifications & Configurable Options Everything you need to make an informed decision Technical Specifications Dimensions Base Unit (no hoppers) ... 39W x 70H x 38D in (99 x 178 x 97 cm) Side mounted hoppers ... 99W x 70H x 38D in (252 x 178 x 97 cm) Rear mounted hoppers ... - Page 6 Ordering Information For genuine Graco products, see your nearest Graco distributor, or call 877-844-7226 For easy ordering, visit www.graco.com/xm and use the Graco XM configuration tool Base Unit Includes: • Frame • Flush pump • Dosing valves Accessory Kits for XM50 and XM70 255963 20-gal (76 l) hopper (heat source not included) 256257...
-
Page 7: Gun Accessories
Airless Guns XTR-5 Airless Spray Gun Maximum working pressure: 5000 psi (345 bar, 34.5 MPa) XTR500 One inch round handle, four-finger trigger, no tip XTR501 One inch round handle, four-finger trigger, 519 flat tip XTR502 Oval-insulated handle, four-finger trigger, 519 XHD RAC tip XTR503 Oval-insulated handle, two-finger trigger, 519 XHD RAC tip XTR504... - Page 8 ABOUT GRACO Founded in 1926, Graco is a world leader in fluid handling systems and components. Graco products move, measure, control, dispense and apply a wide range of fluids and viscous materials used in vehicle lubrication, commercial and industrial settings. The company’s success is based on its unwavering commitment to technical excellence, world-class manufacturing and unparalleled customer service.
