Technical Data - LEYBOLD TURBO.CONTROL i Brief Instructions

Description
4
300680364_002_C0 - 12/2017 - © Leybold
Description
The TURBO.CONTROL i serves to control and monitor a
TURBOVAC i/iX turbomolecular pump.
Only one pump can be controlled and monitored.
The 24 VDC voltage supply can be provided by a plug
power supply with round plug. The power supply unit is
available as an accessory.
The TURBO.CONTROL i has two communication channels
(RS 485 & USB) to the pump control and provides the pos-
sibility of attaching two measuring gauges. Connect a
remote computer via the integrated Ethernet port to the
web server of the TURBO.CONTROL i. Then use the
installed internet browser to control and monitor the pump.
The recorded data can be displayed and evaluated by
means of the external Tool DataViewer.
The TURBO.CONTROL i contains a battery (button cell) for
data buffering.
The TURBO.CONTROL i can be installed in a rack or be
mounted in a table housing provided for it. The table hous-
ing is available as an accessory.
The following measuring gauges can be attached:
PTR 90, PTR 90N, TTR 91, TTR 91N, TTR101, TTR 101N.

Technical Data

Mains input
Dimensions
Ambient temperature
operation
storage
Permissible air humidity
Protection type
Protection class
Weight
24 VDC – 1,5 A – 36 W
106 x 128,5 x 33 mm
0 ...+45 °C
-20 ...+45 °C
< 60% rH,
non-condensing
IP20
III
320 g
