LED Symbol
Red
Green
White
Fig. 4 Monitoring of the operation conditions
Operation
The meanings of the function keys F1 - F4 are shown in
■
the lowest line of the display.
A modified value or setting becomes active by confir-
■
ming with green. If aborted with red, the old value
remains valid.
If the value is again saved by confirming, it remains after
■
a power reset. All the values previously changed are
saved by confirming the query.
The saving procedure may take a few seconds. The
■
pump must not be separated from the supply voltage
during the saving procedure.
LED Status
Off
Flashing
Steady
Steady
Off
Flashing
50 ms on, 500 ms off
Flashing slowly 1/s
Flashing fast 3/s
Steady
Steady
Display
Turbo Pump lost communication
Ethernet Communication Active
300680364_002_C0 - 12/2017 - © Leybold
Operation
Meaning
No System Error
System Warning
TURBO.CONTROL i runs up
System Error
Pump not turning /
no start command active
Start delay > 0 (P36)
Running up
Running down
Normal Operation
