Conforming Use - LEYBOLD TURBO.CONTROL i Brief Instructions

TURBO.CONTROL i
1
6
2
7
3
8
4
9
5
7 TxD/RxD –
8 TxD/RxD +
5
Fig. 2 Pin assignment RS 485

Conforming Use

The TURBO.CONTROL i is intended for operating the
following turbomolecular pumps:
TURBOVAC 90 i(X), 250 i(X), (T) 350 i(X), (T) 450 i(X)
Part Nos.:
810030V1000 to 810089V9999
820050V1000 to 820089V9999
830050V1000 to 830089V9999
Connecting other pumps may lead to pump malfunction.
Standard RS 485 at the
TURBOVAC i basic models
1
6
2
7
3
8
4
9
5
7 TxD/RxD +
8 TxD/RxD –
5
The jumpers on 6/7 and 8/9
Die Brücke auf 6/7 und 8/9
activate the bus termination.
aktiviert die Busterminierung
300680364_002_C0 - 12/2017 - © Leybold
Conforming Use
Optional RS 485
TURBOVAC i(X)
8 TxD/RxD –
9 TxD/RxD +
5
7
