Chapter 10: Operational Test

From a PSTN Office phone attached to a PBX / VoIP Gateway try to make a call to a defined
cellular cell phone in the cellular network around you.
In case of a failure, verify the following:
The PRI is configured properly to your PBX / VoIP gatewa y.
The connection is properly attached and not disconnected.
The cable itself is not malfunctioning.
If your verifications did not have any results, it might be that the c ellular module is not compatible
with the cellular network around you. Make the following handset test, which is mainly used to
check the operation and compatibility of the Multi-Cell system with the local cellular network. Use
the handset with a RJ-11 connection that is supplied with the unit and plug it to the HS socket in
the Multi-Cell Gateway. Follow the handset test instruction as follows:
Press the Handset button: The next screen will appear:
