Chapter 6: Configuration - ISDN Connection Settings
This chapter details ISDN settings starting with overview of the ISDN card in the Multi-Cell PRI
Gateway system and continues with guiding for proper configuration for your needs.
Chapter 6.1: Overview of the ISDN Card
Each Multi-Cell Gateway has a master Printed Circuit Board (PCB). The ISDN card is a small PCB
mounted on the master PCB. The ISDN card is between ports in the Multi -Cell and the switching
unit.
Master PCB
Slave PCB
To define ISDN settings, press.
The ISDN window will be open.
This window defines settings in the E1 line, between the switching unit a nd the ISDN card. Enter
specifications as described on the following page. Ensure that settings are in conformity with
settings in the switching unit.
32 / 54
