Chapter 5.2: Define Work Mode for Port

Press the Advanced tab and the following screen will appear .
Incoming Call Accept or Reject incoming calls to the port.
SIM Switching If you are using a Multi-Cell with 1 SIM per channel, then the options SIM
Swapping and Purse with option 2 are not relevant.
Time Table – The option for the port to work according to d ays and
hours set for the SIMs.
SIM Swapping – When you choose this option, the field "SIM Swapping
(1-255 min)" will be active and you can type how many minutes you
want each SIM to be active before moving to the next SIM in the port.
Purse With Option 1,2,3 – All options works the same in the way that
the port starts with the SIM that has the most units, after all the units in
this SIM end, the port moves to the next SIM which originally had the
second most units and so on, until it finishes all units in the 4 SIMs of the
port.
