Discovery Telecom DTT PRI GSM Ingate User Manual page 45

Status button:
Click this button, to view additional options to work with«
Additional options:
Enable/Disable Port:
Refresh Port:
DTMF Dialer:
Get Cell Information:
Reset Ports X,X:
Reset Statistics:
Read Statistics:
SIM Statistics:
Minutes of the conversation:
Number dialed calls:
Number success calls:
ASR:
ACD:
Choose to enable, or disable the current port
refresh the current port
Engage the built in DTMF dialer, allows sending DTMF
signals
Choose this to get cell information, described above
Reset the ports specified in X
Choose the SIM you want to reset statistics for
Choose the SIM you want to read statistics from
Total call minutes, accumulated on current SIM
Total number of calls made via the current SIM
Number of successful calls made via the current SIM
The percentage of successful calls
Average Time of total calls made via the SIM
45 / 54
