2. In the toolbar press:
3. The configuration computer can be connected to the Multi-Cell in two ways, via the serial
RS-232 cable or via the Ethernet interface. The two options are described in the following
sub chapters.

Chapter 3.1: Management via RS -232 Serial Connection

Connect the RS-232 cable from an available communication port in the computer to the Com socket
in the Multi-Cell Gateway. This is the default setting.
If you are using this type of connection, select "Com Port" in the "Connection mode".
In the selection Pull Down menu, select the computer Com Port number that you are using for your
RS-232 connection with the Multi-Cell PRI Gateway. In Bits per second choose: 115200, the
default Password is: admin.
The Select Connection window opens.
19 / 54
